Automatic Pneumatic Metal Foot Pedal Fuse Fuse Spot Welding Machine
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
-
High-precision automatic custom-made fuse copper welding equipment production line
-
Steel Elevator Panel Sheet Metal Welder Automatic Spot Welding Machine Price For Door Panel
-
Galvanized Steel Elevator Door Multiple Spot Sheet Metal Welding Machine
-
Stiffener Plates Welding Machine Door Panel Table Sheet Metal Spot Welding Machine Price
-
Automatic welding production line for double-head elevator door panels
-
Security Stainless Sheet Door Plate Multi-point Automatic Mobile Type Spot Welding Machine work with loading robot
Product Description
Product Description
Feature
Shanghai Jun Evapotranspiration developed a special welding machine for fuse fuse, built-in Miyaki, designed special fixture, semi-automatic welding, stable welding quality, fast speed and simple operation. Tailored to the fuse fuse. 1kHZ, 4kHz. 8kHzi inverter frequency, high control accuracy; LCD display is intuitive and easy to operate.
1. Using hybrid stepping motor and driver, it has the characteristics of low noise, convenient speed adjustment, wireless speed change and high frequency, large application range, and accurate welding.
2. Use reasonable mechanical spot welding: automatic clamping of the workpiece, automatic welding, automatic displacement, automatic stop after welding, etc.
3. Adopt Miyaji resistance welding control device to ensure stable welding current and product quality.
4. Adopt water cooling device to control the welding temperature within the set range to ensure the safety of the work piece and prolong the service life of the electrode.
Specification
Model | J YD-01L/01AL | J YD-02/02AL | J YD-03/03AL | J YD-04LB | J YD-06AL/AT |
Interior input voltage(V) | 220V/3~380V | 220V/3-380V | 220V/3-380V | 3-380V | 3-380V |
Rated power(KVA） | 4 | 6 | 10 | 12 | 16 |
Maximum output curren(DCA) | 1000 | 2000 | 3000 | 4000 | 6000 |
Rated duty cycle(%) | 20 | 20 | 30 | 10 | 10 |
Inverter frequency(KHZ) | 8/4 | 8/4 | 8/4 | 8/4/1 | |
Welding cycle phase | 11 | 11 | 11 | 11 | 11 |
Welding pulse number | 3 | 3 | 3 | 3 | 3 |
Current slow up and down control | yes | yes | yes | yes | yes |
Storage of specification | 20 groups | 20 groups | 20 groups | 20 groups | 20 groups |
Model size(mm)(LWH) | 435*185*320 | 435*185x320 | 435x185*320 | 460*400*300 | 460*222*345385×200*300 |
Weight(kg) | 1819 | 2220.5 | 22 | 22 | 23.5 |
24 | 24 | ||||
26.5 |
