Carbon Steel Electric Water Heater Production Line Decoiling Line, Decoiler

Technical Parameter

A.   Material spec

Material: Painted sheet, Galvanized sheet, Stainless Steel sheet, etc

Sheet thickness:       0.3~2.0mm

Sheet width:              500~1300mm

Coil ID:                Φ508mm/Φ610mm

Coil OD:              ≤Φ1500mm

Coil Max. Weight:      10T

B.Machine spec

Longitudinal cut number:        Max. 4 (3 pairs cut,one pair cut for backup)

Slitter edge dimension:      5~160mm

Length accuracy:             ±0.5mm

Width accuracy:              ±0.2mm

Diagonal accuracy:           ±0.5mm

Sheet straightness accuracy: ≤0.05mm

Sheet burr:                       ≤6% of sheet thickness

Straighten flatness:         1.0mm/m2

Stacking length:               300~1400mm

Stacking weight:              ≤5T

Stacking accuracy:              ±2mm (4 directions, surface free of scratch)

C.  Other parameter

Production efficiency:          12-16sheet/min(Length=2000mm)

Total wattage:                     around 70KW

Machine occupied area:       around 8*25m

Decoiling direction:       (As per customer actual usage)

1. 12 months free warranty.

2.  Lifetime warranty

3. Technical support

4. Customized
