Product Description

circuit analyzer

general instructions:

This circuit analyzer is a special test device designed for AC low-voltage distribution line quick fault location. With simple operation, accurate measurement and other features, it can detect multiple problems on a line, such as causing to electric shock, electrical fire. abnormal operation of equipment, etc.

Product Description

HT-5908A--Circuit Analyzer

feature
--data storage
--Quickly check the correct wiring
--Identifies proper wiring in 3-wire receptacles
--solve faulty splices and connections,
--solve incorrect wiring
--solve undersized wiring
--solve faulty GFCIs
--solve faulty or incorrectly wired AFCIs
--solve incorrect line voltage
--solve poor ground quality
--TRMS AC voltage measuremen
--ower quality monitor

Functions
--TRMS measuring AC voltage
--Artificialload 12A, 15A, 20A measuring line drop
--Measuring phase voltage, neutral line (zero line )voltage to earth, peak voitage, frequency
--Measuring phase (live line). neutral line (zero line ).earth line conductor impedance
--ldentifying 3-wire socket connection mode (zero for left and live for right, having earth line or not)
--Test the reliability of residual current device (RCD) and response action time
--Test the reliability of GFCI action and response action time
--Backlight function

-- data hold function

Specifications	Range	Resolution	Accuracy
Line voltage	85.0~135.0V	0.1V	±(1.0%+2)
Peak Line Voltage	120.0~190.0V	0.1V	±(1.0%+2)
Voltage with Loading equipments	10.0~135.0V	0.1V	±(2.5%+2)

Line frequency	45.0~65.0HZ	0.1HZ	±(1.0%+2)
Impedance-live and Neutral & Earth	0.00~3.00Ω	0.01Ω	±(2.5%+2)
	>3.00Ω	0.01Ω	NO ensure
Neutral-Ground Voltage	0.0~10.0V	0.1V	±(2.5%+2)

RCD trip time	1ms~6.5S	1mS	±(1.0%+2)
RCD trip current	30mA~37mA	0.1mA	±(1.0%+2)
GFCI trip time	1ms~6.5S	1mS	±(1.0%+2)
GFCI trip current	6mA~9mA	0.1mA	±(1.0%+2)

Voltage drop	0.1~99.9%	0.1%	±(2.5%+2)
Voltage drop load current	12/15/20A
General
Power supply	6*1.5V AAA Batteries

Product size	194mm78mm37mm/7.64"3.07"1.46"
Product weight	254g/0.56lb
Certificate	CE/ETL/RoHS
Safety rating	CAT III 300V

Accessories include
Power cord
Carry bag
Battery and user´s manual
