Help Center2000KN Digital Display Concrete Compression Testing Machine Concrete Pressure Testing Machine
Related Products
-
Research Department (RD) Institution Compression Testing Machine for Concrete 2000KNNegotiableMOQ: 1 -
YES-300 Digital Display Brick Flexural and Compression Test Equipment ,compressive TesterNegotiableMOQ: 1
-
YAW-2000D 2000KN Cement Concrete Block Construction Material Compressive Testing Machine Good PriceNegotiableMOQ: 1
-
YAW-1000D 100Ton Mortar Cement Brick Concrete Compression Testing MachineNegotiableMOQ: 1
-
YAW-100D Electronic MotoR Cement Compressive Flexural Strength Testing MachineNegotiableMOQ: 1
cement block compression testing machine /compressive test equipment for concrete and brick
Bending and compression testing machine application:
This machine adopt computer auto control, with constant test speed, constant stress, test force keeping and other control mode. The computer realize test data and test curve’display, save,manage function, can print test report. With special fixtures, can test other material compression and flexual testing.
Features and Function:
1. This testing machine adopt AC servo system drive the AC servo motor,by precision reduction gears drives the ball screw,with high test accuracy,low noise.
2. Without pressure oil leakage and proportional valve blocking, low noise, more reliable.
3. Window control and dealing software, design more reasonable.
can arbitrarily set pressure value, pressure time, auto calculate test result.
4. Advanced auto control function, can do single or batch test.
5. Auto stop,after sample broken.
6. With over load protection.
Main Specification
|
Model |
YES-2000 |
YES-1000 |
|
Max. load |
2000kN/200Ton |
1000kN/100Ton |
|
Machine Class |
1 class |
|
|
Testing space adjust method |
Manual adjust |
|
|
Minimum resolution |
0.1kN |
|
|
Piston stroke |
30mm |
|
|
Diameter of piston |
250mm |
|
|
Distance between platens |
320mm |
|
|
Upper&lower platen size |
220*250mm (Can be customized) |
|
|
Power supply |
AC380V/50Hz/3 phase(can be customized) 0.75kw |
|
|
Size |
880*480*1400 mm |
|
|
Weight |
600kg |
|
Standards:
GB/T, ISO, ASTM, DIN, JIS, etc.
Compression testing machines in stock:
CE certificate:
Our compression testing machines can be delivery within 3 working days --5 working days after receiving payment, the products can be shipped by air, by sea or by express delivery !
Dear customer, if you need our testing machines, please contact with us without any hesitate ! We will supply our best service for you !
