WAW-1000D Computer hydraulic utm 1000 ton capacity tensile testing machine
- 1000 per Month
- T/T Credit Card
- Construction iron bars hydraulic cylinder test bench/hydraulic pressure universal bending testing machine
- HST 10 - 200 Ton UTM Hydraulic Universal Tensile Testing Machine
- ASTM CE 300ton 3000kn utm Hydraulic Universal Tensile Testing Machine tensile testing machine price
- 2021 New Model Steel Bar /Steel Strand Single Column Hydraulic Universal Tensile Testing Machine/Equipment
- WAW-F Series Electro-hydraulic Single Space Servo Universal Testing Machine
- WE-300 300KN 30Ton tensile tester with preload testing rig load cell display
Product Description
WAW-1000 D/E 1000 kn Steel Computer Servo utm 1000 ton capacity tensile testing machine
Contact: Alice Skype: hssdtest whatsapp /wechat/mobile:17853101076
1. Application
Universal Tensile Strength Testing Machine price is suitable for tension, compression,
bending, shearing,peeling, tearing and other tests by adding different test fixture for metal and nonmetal materials. It is widely used in inspection department, engineering area, laboratories, universities and institutes for material properties research and quality control.
2. Standards of universal testing machine price
ISO75001, ASTM A370, ASTM E4, ASTM E8 and BSEN standards
3. Main specifications universal testing machine price
Model | WAW-100D | WAW-200D WAW-300D | WAW-600D | WAW-1000D/E | WAW-1200E | ||||
Control Way | Constant stress uniform deformation constant displacement three closed loop control and program control dealing | ||||||||
Number of Screw drivers | 4 | ||||||||
Max. Load(KN) | 100 | 200 /300 | 600 | 1000 | 1200 | ||||
Load Accuracy | ≤± 1%/ ≤± 0.5% | ||||||||
Load Range | 2%~100%FS | ||||||||
Load Resolution | 1/300000 | ||||||||
Deformation Measurement Range | 2%~100%FS | ||||||||
Deformation Accuracy | ≤± 1% | ||||||||
Displacement Resolution | 0.01mm | ||||||||
Testing speeds (mm/min) | 0.1~118 | 0.1~123 | 0.1~123 | 0.1~70 | 0.1~70 | ||||
Adjustable crosshead speed(mm/min) | 450 | 450 | 350 | 350 | 320 | ||||
Displacement Error | ≤±0.5% | ||||||||
Max. Piston Stroke(mm) | 200 | 200 | 200 | 200/250 | 250 | ||||
Max. Tension Test Space (mm) | 780 | 780 | 900 | 950/980 | 930 | ||||
Max. Compression Test Space | 550 | 550 | 650 | 700 | 640 | ||||
Column Effective Spacing(mm) | 485 | 485 | 500 | 560/580 | 610 | ||||
Clamping Method | Hydraulic Automatic Clamp | ||||||||
Flat Specimen Clamping Width(mm) | 80*80 | 80*80 | 90*90 | 100*100 | 120*110 | ||||
Compression Plate Size | Φ 160mm | ||||||||
Bending Roller Distance | 450mm | ||||||||
Width Of Bending Rollers | 120mm | ||||||||
Power Supply | 3-phase, AC380V, 50Hz (Can Be Customized) |
