300KN 30Tonne tensile tester with preload testing rig load cell display

WE-300 300KN 30Ton tensile tester with preload testing rig load cell displayWE-300 300KN 30Ton tensile tester with preload testing rig load cell displayWE-300 300KN 30Ton tensile tester with preload testing rig load cell display

Product Application



The machine adopts hydraulic loading, digital display, easy and convenient to operate. It is mainly used to execute the tension, compression, bending, shearing etc. Mainly test for metal materials.



Attached with simple accessories and devices, it can be used to test wood, concrete, cement, rubber and so on. It is very suitable for making test to different metal or nonmetal materials under high toughness and hardness against extreme big loading force.

Specification Data

  Digital meter display hydraulic universal Testing machine specification :

Model

WE-300D

WE-600D

WE-1000D

Max. Load (KN)



300 KN

600 KN

1000 KN

Transmission style



hydraulic cylinder transmission

Control method



Manual control, digital meter display

Load Accuracy



≤±1%

Load Range



2%~100% of Full Scale

Round specimen clamping diameter (mm)

Φ10-Φ32

Φ13-Φ40

Φ13-Φ50

Flat specimen clamping thickness  (mm)

0-15mm

0-15mm

0-30mm

Flat specimen clamping width (mm)

70mm

70mm

75mm

Compression platen size (mm)



Φ160 /Φ240

piston stroke (mm)



250mm

Power Supply



AC110V / 220V / 380V±10%, 50HZ-60HZ
