WAW-D Computer Control Electric servo Hydraulic Universal Testing Machine
Application:
This machine is mainly used to process tensile test,compression test , bending test and shearing test of metallic material.it can also be used to process compression test and bending test of cement,brick,tile,rubber and other nonmetallic material. With special auxiliary equipment it can also be used process mechanical property test of fastener, steel wire rope, components . It applies to aerospace industry, engineering inspection, university and college, mining industry , research institution and other fields.
Features:
1. It has three parts: Host & oil source &measurement control system
2. Automatic rise, down, test and stop
3. Deepen jaw seat can prevent trumpet-shaped deformation as non-uniform stress in the test, can improve the soundness and life, make holding more firm and smooth
4. Between the jaw seat and jaw plate added wear-resisting backing board, protect the jaw seat and card plate, making the jaw seat more flexible
5. Between the host base and screw using the cone bearing which make screw rotation more stable and reliable, while solved the gap influence in the test progress
5. All inclusive type host designed to ensure that its super stiffness to resist loads trace deformation
Technical parameter:
|
Model |
WAW-100E WEW-100E |
WAW-300E WEW-300E |
WAW-600E WEW-600E |
WAW-1000E WEW-1000E |
WAW-2000E WEW-2000E |
|
Number of Screw drivers |
4 |
||||
|
Max. Load (KN) |
100 |
300 |
600 |
1000 |
2000 |
|
Load Accuracy |
≤± 1%/ ≤± 0.5% |
||||
|
Load Range |
2%~100%FS/ 0.4%~100%FS
|
||||
|
Load Resolution |
1/300000 |
||||
|
Deformation Measurement Range |
2%~100%FS |
||||
|
Deformation Accuracy |
≤± 1% |
||||
|
Displacement Resolution |
0.01mm |
||||
|
Displacement Error |
≤±0.5% |
||||
|
Max. Piston Stroke(mm) |
200 |
200 |
250 |
250 |
250 |
|
Max. Tension Test Space(mm) |
780 |
780 |
800 |
980 |
1000 |
|
Max. Compression Test Space(mm) |
550 |
550 |
550 |
700 |
750 |
|
Column Effective Spacing(mm) |
485 |
485 |
500 |
560 |
700 |
|
Clamping Method |
Hydraulic Automatic Clamp |
||||
|
Tensile fixture |
round :Φ10-Φ20, Φ20-Φ32 Flat :0-15mm |
round :Φ10-Φ20, Φ20-Φ32 Flat :0-15mm |
round :Φ13-Φ26, Φ26-Φ40 Flat :0-15mm |
round :Φ13-Φ26, Φ26-Φ40 Flat :0-15mm |
round :Φ15-Φ30, Φ30-Φ55,55-Φ70, Flat :10-40,40-70mm |
|
Flat Specimen Clamping Width(mm) |
80*80 |
80*80 |
90*90 |
100*100 |
150*120 |
|
Compression Plate Size |
Φ 160mm |
||||
|
Power Supply |
3-phase, AC380V, 50Hz (Can Be Customized) |
||||
