Help CenterHydraulic Cylinder Head Crack Tearing Testing Machine
Related Products
-
1000kn 100 Ton Digital Hydraulic Servo Hydraulic Tensile Test Machine for Tension/compression and BendingNegotiableMOQ: 1 -
M10 M12 M16 M20 M24 M30 Bolt and Nut Tensile Test EquipmentUS$ 90272.91 - 90972.70MOQ: 1 Set
-
Hydraulic High Voltage Porcelain Insulator Tensile Compression Bending Testing MachineNegotiableMOQ: 1
-
200 TON Hydraulic Universal Steel Tensile Strength Testing Machine PriceNegotiableMOQ: 1
-
1000KN Steel Bar Screw Bolt Hydraulic Universal Tensile Bending Shearing Testing Equipment/test InstrumentsNegotiableMOQ: 1
600KN hydraulic servo universal testing machine
Hydraulic Universal Testing Machine is suitable for tension, compression, bending, shearing, peeling, tearing and other tests by adding different test fixture for metal and non-metal materials. It is widely used in inspection department, engineering area, laboratories, universities and institutes for material properties research and quality control.
Good price for computer display hydraulic universal Testing machine specification :
|
Model |
WEW-100D |
WEW-300D |
WEW-600D |
WEW-1000D |
WEW-2000D |
||||||||
|
Structure |
6 column |
||||||||||||
|
Control mode |
loading process manual control,computer automatic data dealing |
||||||||||||
|
Max. Load |
100KN |
300KN |
600KN |
1000KN |
2000KN |
||||||||
|
Tension test space |
650mm |
750mm |
|||||||||||
|
Compression Test Space |
500mm |
600mm |
|||||||||||
|
Round specimen clamping diameter (mm) |
Φ4-Φ21 |
Φ10-Φ32 |
Φ13-Φ40 |
Φ13-Φ50 |
Φ15-Φ70 |
||||||||
|
Flat specimen clamping thickness (mm) |
0-15mm |
0-30mm |
0-60mm |
||||||||||
|
Flat specimen clamping width |
70mm |
75mm |
85mm |
||||||||||
|
Compression plate size |
φ160mm/φ240mm |
Φ240mm |
|||||||||||
|
Bending roller distance |
450mm |
||||||||||||
|
Width of bending rollers |
120mm |
160mm |
|||||||||||
|
Load accuracy |
≤±1% or ≤± 0.5% |
||||||||||||
|
Load range |
2%-100%of Full Scale or 0.4%-100% of Full Scale |
||||||||||||
|
Load resolution |
1/300000 of Full Scale |
||||||||||||
|
Deformation Measurement Range |
2%~100% of Full Scale |
||||||||||||
|
Deformation accuracy |
≤±1% or ± 0.5% |
||||||||||||
|
Displacement resolution |
0.01mm |
||||||||||||
|
Displacement accuracy |
≤±0.5% |
||||||||||||
|
Piston stroke |
250mm |
||||||||||||
|
Lifting speed of mobile beams |
150mm/min |
||||||||||||
|
Clamping method |
Hydraulic clamp |
||||||||||||
|
Power supply |
3-phase, AC380V, 50Hz(can be customized) |
||||||||||||
