used concrete compression test machine/Asphalt mixture universal testing machine
The machine adopts hydraulic loading, digital display, easy and convenient to operate. It is mainly used to execute the tension, compression, bending, shearing etc. Mainly test for metal materials.
Attached with simple accessories and devices, it can be used to test wood, concrete, cement, rubber and so on. It is very suitable for making test to different metal or nonmetal materials under high toughness and hardness against extreme big loading force.
Digital meter display hydraulic universal Testing machine specification :
|
Model |
WE-300D |
WE-600D |
WE-1000D |
|||
|
Max. Load (KN)
|
300 KN |
600 KN |
1000 KN |
|||
|
Transmission style
|
hydraulic cylinder transmission |
|||||
|
Control method
|
Manual control, digital meter display |
|||||
|
Load Accuracy
|
≤±1% |
|||||
|
Load Range
|
2%~100% of Full Scale |
|||||
|
Round specimen clamping diameter (mm) |
Φ10-Φ32 |
Φ13-Φ40 |
Φ13-Φ50 |
|||
|
Flat specimen clamping thickness (mm) |
0-15mm |
0-15mm |
0-30mm |
|||
|
Flat specimen clamping width (mm) |
70mm |
70mm |
75mm |
|||
|
Compression platen size (mm)
|
Φ160 /Φ240 |
|||||
|
piston stroke (mm)
|
250mm |
|||||
|
Power Supply
|
AC110V / 220V / 380V±10%, 50HZ-60HZ |
|||||
Send Inquiry to This Supplier
