KASON 300kn 400kn 500kn Computer Controlled Steel Strand Tensile Stress Relaxation Testing Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Trading Company
Year Established:
2016
Annual Export Value:
US$2.5 Million - US$5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
KASON Stress Relaxation Technique MeterNegotiableMOQ: 1 -
KASON Steel Strand Tensile Stress Test MachineNegotiableMOQ: 1
-
KASON 10ton/100ton Universal Wire Rope Pull Force Tensile Strength Testing MachineNegotiableMOQ: 1
-
KASON Cable Chain Webbing Sling Tensile Strength Testing MachineNegotiableMOQ: 1
-
LAW-1000G 1000kN Automatic Strand Steel Wire Tensile Testing MachineNegotiableMOQ: 1
Multifunctional 300ton used concrete digital display machine 2000kn manual compression testing machines with CE certificate
Product Description
SXW 400 Computer Control Steel Strand Tensile Stress Relaxation Testing Machine used to test the relaxation properties of the
Steel Strand, Steel Bars and Stress Wires. using advanced Gear Of Tooth Modification technology, to ensure that testing machine
structure compact, achieve precise measurement results, at the same time with high-quality accessories, to achieve efficient
measurement.
This machine meet these <> and <> standards of steel at room temperature tensile stress relaxation test requirements.
This machine widely used in Quality Inspection Departments, Construction Building Entities, Steel Strand and Reinforced
Manufacturing Companies and so on. It is a new model testing machine for Modern Building Mechanical Tests.
Specification
Model |
SXW-400 |
Host Structure |
Horizontal Type |
Max. Test Force |
400 KN |
Test Force Range |
2%~100% (6 KN~300 KN) |
Accuracy Of Testing Force |
Better Than ±0.5% Of Indicated Value |
Test Force Resolution |
10 N |
Max. Relaxation Test Space |
2000 mm (Do Not Including Stretching Stroke) |
Chucks Displacement Resolution |
0.001 mm |
Stretching Stroke |
200 mm |
Digital Micrometer |
Range: 10 mm, Resolution: 0.001 mm |
Test Force Indication Relative Error |
±1% |
Temperature Resolution |
0.1 °C |
Displacement Measurement Accuracy |
≤±0.5%FS |
Chucks Moving Speed |
0-20 mm/min |
Clamping Specimen Diameter |
φ9.53, φ12.7, φ15.24. OR Other Diameter Depend On Customers' Requirements |
Constant Speed Control Accuracy |
≤±1% (Set Value) |
Test Time |
More Than 1000 Hours |
