Home > Instruments & Meters > Test Instrument > Test Machine > KASON Steel Strand Tensile Stress Test Machine
KASON Steel Strand Tensile Stress Test Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Trading Company
Year Established:
2016
Annual Export Value:
US$2.5 Million - US$5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
KASON 10ton/100ton Universal Wire Rope Pull Force Tensile Strength Testing MachineNegotiableMOQ: 1 -
KASON Cable Chain Webbing Sling Tensile Strength Testing MachineNegotiableMOQ: 1
-
LAW-1000G 1000kN Automatic Strand Steel Wire Tensile Testing MachineNegotiableMOQ: 1
-
600KN 60TON Precise Hydraulic Instron Used Universal Tensile Testing Machine PriceNegotiableMOQ: 1
-
Hot Selling Technique Stress Relaxation Astm With Low PriceNegotiableMOQ: 1
KASON Projector CST-50
Product Description
Application
This machine is mainly used in the tensile mechanical properties test of the steel strand wire test. Widely used in space flight
and aviation, petrochemical industry, mechanical manufacture, plastic, rubber, ceramic, building materials, metal material,
constructional engineering and university and college, mining industry, research institution and other fields.
2.Product description
Main components: Host, oil source, measurement and control system, manual control the test process, computer dispose the test data
and calculate FM, RPO.2, RM and Ft test result of the materials automatically after stop.
3.Technical parameter
Specification
Model |
LAW-600H |
LAW-1000H |
|
Max.test force(kN) |
600 |
1000 |
|
Structure |
4 columns two ball screws, chain transmission, oil cylinder down-setting type |
||
Test machine class |
1 Class |
||
Test force range（FS） |
2%-100% |
||
Relative error of force reading(%) |
≥±1 |
||
Test force resolution |
1/20000 |
||
Deformation measurement range (FS) |
2%～100% |
||
Deformation resolution |
1/20000 |
||
Relative error of deformation reading (%) |
≥±0.5 |
||
Displacement resolution (mm) |
0.01 |
||
Relative error of displacement reading (%) |
≥±0.5% |
||
Effective column space (mm) |
600 |
730 |
|
Tension fixtures configuration |
Hydraulic automatic clamping type |
||
Stranded wire clamping range(mm) |
Ф12.7 or Ф15.2 or Ф15.2 mm |
||
Power supply |
380V/50Hz/Three-phase four-wire system |
||
Compression grip |
Φ160 sphere automatically leveling compression grip |
||
Related Products
Please contact KASON directly for best quotation
