WAW-3000A/4000A/5000A 3000~5000KN Computer Control Servo Hydraulic Universal Testing Equipment Machine Price
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Trading Company
Year Established:
2016
Annual Export Value:
US$2.5 Million - US$5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
WAW-1000D UTM 1000kN 100Ton Hydraulic Universal Mechanical Tensile Testing MachineNegotiableMOQ: 1 -
WAW-2000D 2000KN Computer Control Hydraulic Tensile Compression Strength Testing MachineNegotiableMOQ: 1
-
WAW-300D 300kN Tensile Compression Test 30TON Hydraulic Universal Testing MachineNegotiableMOQ: 1
-
WAW-600D 60Ton Hydraulic Universal Testing Machine For Steel MaterialNegotiableMOQ: 1
-
WAW-1000D 1000KN Computer Control Electro Hydraulic Servo Hydraulic Universal Testing Machine/Pull Test EquipmentNegotiableMOQ: 1
Product Description
WAW-3000A/4000A/5000A 3000~5000KN Computer Control Servo Hydraulic Universal Testing Equipment Machine Price
Application
For static and cuasi-static test (low frequency fatigue) for high loads in many types of tests. Specially indicated to switch test mode, thanks to its dual space design.
EN 10002-2; ASTM E4, ISO 7500-1; DIN 51221 and BS1610 guide, etc.
For static and cuasi-static test (low frequency fatigue) for high loads in many types of tests. Specially indicated to switch test mode, thanks to its dual space design.
Standards
EN 10002-2; ASTM E4, ISO 7500-1; DIN 51221 and BS1610 guide, etc.
Specification
Model | WAW-3000A | WAW-4000A | WAW-5000A | ||
Control Way | Constant stress uniform deformation constant displacement three closed loop control and program control dealing | ||||
Max. Load(kN) | 3000 | 4000 | 5000 | ||
Load accuracy | Class1 | ||||
Load range | 2%～100%F·S | ||||
Load resolution | Capacity/300, 000 (fully auto scaling of single measurement | ||||
Deformation Measurement Range | 2%~100%FS | ||||
Stroke | 250mm | 300mm | 300mm | ||
Test speed(mm/min) | 0-80 | ||||
Max. Tension Test Space (mm) | 800 | 1000 | 1000 | ||
Load frame(mm) | 1700*1400*4500（5500） | 2000*1600×4800（6100） | 2000*1600*4900（6300） | ||
Weight(kg) | 8500 | 20000 | 22000 | ||
