Home > Instruments & Meters > Test Instrument > Test Machine > WDW-100E 100kN Load Accuracy 0.5 Class Computerized Electronic Universal Tensile Testing Machine
WDW-100E 100kN Load Accuracy 0.5 Class Computerized Electronic Universal Tensile Testing Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Trading Company
Year Established:
2016
Annual Export Value:
US$2.5 Million - US$5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
WDW-1 Single Column Computerized Universal Sewing Thread Tensile Testing Machine for Rubber Tensile TestsNegotiableMOQ: 1 -
WDW-10 10kN Electronic Universal Tensile Strength Testing MachineNegotiableMOQ: 1
-
WDW-20 20kN Electronic Universal Tensile Strength Testing Machine Hand Operated Compression Testing MachineNegotiableMOQ: 1
-
WDW-1 Single Column Computerized Universal Tensile Testing MachineNegotiableMOQ: 1
-
WDW-20 20kN Tension Testing Machine Electronic Universal Tensile Strength Testing Machine EquipmentNegotiableMOQ: 1
Product Description
Application
This series material testing machine product group was primarily developed for
standardized tests on ma- terials and components. Used in conjunction with the intuitive HKtest software.
Test Typical: wide range of tension, compression, bending, shearing and low cycle test, include metal, building components, rubber, plastic, spring, high strength steel (HSS), aerospace and automotive structures, screws, nuts,large fasteners, wood products etc.
ASTMA370, ASTME4, ASTME8, ASTME9, ASTM D638, ASTM D882, ASTM D3039,ASTM, D3479, ASTM E517,ASTM, D695, ASTM D6641, ASTM D3410, ASTM D7791, ASTM D412, ISO6892, ISO527-3, ISO527-4, ISO7438, ISO7500-1, EN10002-4, GB/T228-2002, GB16491-2008, HGT 3844-2008 QBT 11130-1991, GB13-22-1991, HGT 3849-2008, GB6349-1986, GB/T 1040.2-2006, ASTM C165, EN826, EN1606, EN1607, EN12430 etc.
Stroke protection: Machinery,computer double protection, prevent over preset; Force protection: system setting, Emergency stop device: handing emergencies.
This series material testing machine product group was primarily developed for
standardized tests on ma- terials and components. Used in conjunction with the intuitive HKtest software.
Test Typical: wide range of tension, compression, bending, shearing and low cycle test, include metal, building components, rubber, plastic, spring, high strength steel (HSS), aerospace and automotive structures, screws, nuts,large fasteners, wood products etc.
Standards
ASTMA370, ASTME4, ASTME8, ASTME9, ASTM D638, ASTM D882, ASTM D3039,ASTM, D3479, ASTM E517,ASTM, D695, ASTM D6641, ASTM D3410, ASTM D7791, ASTM D412, ISO6892, ISO527-3, ISO527-4, ISO7438, ISO7500-1, EN10002-4, GB/T228-2002, GB16491-2008, HGT 3844-2008 QBT 11130-1991, GB13-22-1991, HGT 3849-2008, GB6349-1986, GB/T 1040.2-2006, ASTM C165, EN826, EN1606, EN1607, EN12430 etc.
20 kn tensile testing machine 20kn 50kn 100kn universal test machine 20kn 50kn 100kn universal testing machine 20kn computerized universal tensile compressiontesting machine 20kn ring stiffness testing machine 20kn tear strength test machine 20kn tensile tester
Safety Device
Stroke protection: Machinery,computer double protection, prevent over preset; Force protection: system setting, Emergency stop device: handing emergencies.
Specification
Items |
Model |
||||||||
WDW-10E |
WDW-20E |
WDW-30E |
WDW-50E |
WDW-100E |
|||||
Structure |
Column and 2 Ball Screw |
||||||||
Max. Load(kN) |
10 |
20 |
30 |
50 |
100 |
||||
Tensile space(mm) |
670 |
770 |
650 |
||||||
Compression space(mm) |
900 |
1000 |
|||||||
Effective test width |
450 |
550 |
|||||||
Size(mm) |
850 * 590 * 1750 |
840*570*1850 |
950*660*2000 |
||||||
Host Weight (kG) |
370 |
420 |
680 |
||||||
Power Supply |
220V/50-60Hz |
||||||||
Company Profile
Packing & Delivery
Standard exporting case
