Corrosion Resistance FRP Epoxy Fiberglass Plastic Threaded Rod Screw Bolt and Nut
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Distributor/Wholesaler
Year Established:
2000
Annual Export Value:
US$50 Million - US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Thailand Market Yellow Color 400mmm Width FRP Grating Solar Rooftop WalkwayNegotiableMOQ: 1 -
Custom Aquarium Fish Tank Fiberglass Frp Fish Tank Above Ground Commercial Use Marine Water Fish Farming TankNegotiableMOQ: 1
-
GRP FRP Designable FRP Panel Molded Fiberglass Reinforced Plastics Grating FloorNegotiableMOQ: 1
-
Customized Frp Grp Round Square Fish Tank Fiberglass Composite Gelcoat Fish Farming TankNegotiableMOQ: 1
-
Factory Supply Fiberglass Car Wash Grate Floor Plastic FRP Walkway GratingNegotiableMOQ: 1
Product Description
Title goes here.
FRP fiberglass bolts and nuts are made of glass fiber filaments impregnated with epoxy resin matrix by high temperature pultrusion. The company adopts a full CNC vacuum demoulding and pultrusion technology production line, which has reached the current domestic level. It is equipped with an online speed tracker, a temperature control system, and improves the uniformity and heat resistance of the insulating rod. It is produced by Bipu FRP and unsaturated resin. The equipment has better stability and controllability. This product is suitable for use in electrolytic aluminum plants, where the short-circuit port of the electrolytic cell is used as an insulating bolt. It is an ideal substitute for MPI insulation bolts.
Specification
1,Long-term working temperature:170—200℃
Maximum short-circuit working temperature:230℃
Size:Ø8、Ø10、Ø12、Ø16、Ø17、Ø18、Ø20、Ø22、Ø24、Ø25、Ø26、Ø30、Ø32、Ø34、Ø35、Ø36、Ø38、Ø40、Ø42、Ø43、Ø44、Ø45、Ø50、Ø60、Ø70
Length: Accept customized
Item |
Technical index |
Density (g/cm3) |
≥2.1 |
Tensile Strength(Mpa) |
≥1360 |
Siphon test(Min） |
＞20 |
Water diffusion test (mA) |
＜0.03 |
Withstand voltage test(kV) |
＞100 |
Stress corrosion(h） |
＞96 |
Bending strength(Mpa) |
＞100 |
Hot bending strength(Mpa) |
≥260 |
Volume resistivity(Ω.m) |
≥1012 |
Fiber content (%) |
≥80 |
Power frequency breakdown voltage (Kv/cm ) |
≥100 |
Full wave impulse voltage (Kv/cm ) |
≥95 |
Water absorption (%) |
＜0.05 |
Product Features
Due to the continuous pultrusion of the product, each glass filament in the product is guaranteed to be a whole filament, which makes the product's resistance to mechanical pressure and mechanical tension very excellent, and the product's tensile strength is 570 Mpa. Excellent electrical performance, withstand voltage rating of 10KV---1000KV voltage range, strong corrosion resistance, high bending strength, not easy to bend, easy to use and other characteristics.
