Plastic Random Media Material Bio Ring for Absorption Tower Packing
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Distributor/Wholesaler
Year Established:
2000
Annual Export Value:
US$50 Million - US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Anti-floating Aeration System Tubing Air Hose Self Sinking 3/8\NegotiableMOQ: 1 -
China Supplier Matte Surface UPE Non-porous Self Sinking HoseNegotiableMOQ: 1
-
Fishing Farm PVC Aeration Hose 3/8\" ID Self Sinking HoseNegotiableMOQ: 1
-
14mm*9.5mm Aquaculture Farming Aeration Hose Self Sinking HoseNegotiableMOQ: 1
-
MBBR MediaNegotiableMOQ: 1
Plastic Random Media Material Bio Ring for Absorption Tower Packing
Bio Ring / P A L L ring is made from heat resistant and chemical corrosion resistant plastic, for instance, polypropylene (PP). An advance on the Raschig Ring, the Pall Ring has similar cylindrical dimensions but has two rows of punched out holes, with fingers or webs turned into the center of the cylinder, which significantly increases the performance of the packing, in terms of throughput, efficiency and pressure drop.
Material |
Model |
Size |
Number per volume |
Surface area |
Void Volume |
Dry Packing Factor |
D*H*δ mm |
n/m3 |
m2/m3 |
% |
m-1 |
||
PE, PP, RPP, PVC, CPVC, PVDF, etc
|
Dg16 |
16×16×1.0 |
180000 |
274 |
90 |
376 |
Dg25 |
25×25×1.2 |
49000 |
213 |
91 |
285 |
|
Dg38 |
38×38×1.4 |
13600 |
151 |
91 |
200 |
|
Dg50 |
50×50×1.5 |
6300 |
100 |
92 |
130 |
|
Dg76 |
76×76×2.6 |
1830 |
72 |
92 |
92 |
Product Feature
* Higher capacity and lower pressure drop.
* Multiple sizes provide ability to optimize capacity and efficiency based on application requirements.
* Relatively high liquid hold-up allows good absorption efficiency with slow chemical reaction.
* Lower sensitivity to liquid and vapor distribution quality allows usage with conventional liquid distributors.
* Ring and spoke construction provides high mechanical strength, which allows usage in deep beds.
Produdct Application
1. Ethylene extraction columns
2. Mass transfer columns separation services
3. Carbon dioxide and hydrogen sulphide absorbers and flash tower
4. Liquid extractors
5. Carbon monoxide converters
6. Dimethyl terephthalate running column
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services would be provided.
Usually the bio packing rings are packed with carton box, or woven bag, or jumbo bag.
Why Choose Us?
1. Highest quality
We are the manufacturer who adopts imported raw materials to guarantee the high quality.
2. Most competitive price
We can adjust the price according to your market demand changes, and also can launch a series of promotional activities in a bad economic environment.
3. Professional
We have a complete team, including development, procurement, production, inspection, sales and after-sale service.
4. Best service
We would give feedback within 24 hours. For any question or problem, we would try our best to help.
Trust, High quality and Best service build long term win-win business.
Our Service
1. High Quality: Excellent quality is our first pursue, we have strict quality control by our QC team.
2. Big Capacity: Constantly introducing new equipment to meet clients production requirement and market change.
3. Professional Team: Professional development team, purchase team, production team, inspection team, sale team, to provide the best service for our customers.
4. High Efficiency: 24 hours online service (Email, Trademanager, WhatsApp, Wechat) to solve all your questions.
5. Customization: Size & shape could be made as customer requirement.
6. Payment: Flexible payment ways, making the payment more convenient and easy.
Welcome your inquiry, we would give feedback within 24 hours.
