Industrial Corrosion Resistant Fiberglass Frp Grating Frp Plastic Platform Grating
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Distributor/Wholesaler
Year Established:
2000
Annual Export Value:
US$50 Million - US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
38mm*38mm Frp Walkway Fiberglass Floor GrateNegotiableMOQ: 1 -
High Strength Anti Corrosion Molded Plastic FRP GRP Fiberglass Grating PanelNegotiableMOQ: 1
-
Black Fiberglass Grating Anti Slip Frp Grating for FloorNegotiableMOQ: 1
-
High Strength Surface Drainage FRP Pultrusion Grating Fiberglass Grating for Heavy DutyNegotiableMOQ: 1
-
High Strength Composite Fiberglass Frp Decking Solid Pultruded Frp Grating for Flooring PanelsNegotiableMOQ: 1
Product Description
Industrial corrosion resistant fiberglass frp grating frp plastic platform grating
FRP gratings are ideal materials for operation platforms, including normal operation platforms, offshore oil platforms and tank deck platforms.
Operating platform:
Many chemical plants have a large number of operating platforms, and those which FRP gratings as surface materials are corrosion resistant, no paint, no maintenance with long service life of fifteen to twenty years. Its weight is three-quarters lighter than steel gratings, so there is no need of lifting equipment when installing. It is very easy to trepan and cut FRP gratings by arc cutting saw, and it won't lead to the change of mechanical properties or the scattering of grid, so as to meet the requirements of installation. In addition, the appropriate design making the FRP gratings have some elasticity, which can reduce the fatigue of workers who work over a long period of time. Therefore improve the work efficiency.
Many chemical plants have a large number of operating platforms, and those which FRP gratings as surface materials are corrosion resistant, no paint, no maintenance with long service life of fifteen to twenty years. Its weight is three-quarters lighter than steel gratings, so there is no need of lifting equipment when installing. It is very easy to trepan and cut FRP gratings by arc cutting saw, and it won't lead to the change of mechanical properties or the scattering of grid, so as to meet the requirements of installation. In addition, the appropriate design making the FRP gratings have some elasticity, which can reduce the fatigue of workers who work over a long period of time. Therefore improve the work efficiency.
There is no need of lifting equipment when installing FRP gratings, and they are easy to cut into any sizes.
Using FRP gratings as the surface of platforms are corrosion resistant, and can reduce the fatigue of workers
Offshore oil platform:
Traditional offshore oil platforms often use steel as surface material, but the bad weather and the sea erosion caused severe corrosion to these materials, which increase insecurity factors. Most foreign countries have successfully applied FRP gratings into this hostile environment. Due to the lightweight, the basic support components are easy to handle and the costs of platform are reduced through rational designation.
Traditional offshore oil platforms often use steel as surface material, but the bad weather and the sea erosion caused severe corrosion to these materials, which increase insecurity factors. Most foreign countries have successfully applied FRP gratings into this hostile environment. Due to the lightweight, the basic support components are easy to handle and the costs of platform are reduced through rational designation.
We can produce many colors Industrial corrosion resistant fiberglass frp grating frp plastic platform grating , such as yellow, green, Blue, Red ,Gray, black, white and so on, we also accpet customized color according the RAL color card number.
Industrial corrosion resistant fiberglass frp grating frp plastic platform grating is composed of alternating directional layers of continuous glass fiber for strength, with resin to
consolidate the fibers and provide the shape and corrosion-resistance. Molded grating has very high impact tolerance, as well as
the highest chemical resistance of any fiberglass grating. It can be made slip-resistant by adding grit to the surface.
consolidate the fibers and provide the shape and corrosion-resistance. Molded grating has very high impact tolerance, as well as
the highest chemical resistance of any fiberglass grating. It can be made slip-resistant by adding grit to the surface.
Specifications(mm) |
a*b(mm) |
weight(kg) |
38*38*25 |
1220*3660 |
54 |
38*38*30 |
1220*3660 |
70 |
38*38*38 |
1220*3660
1000*4007
|
88
81
|
50*50*50 |
1220*3660 |
98 |
19*19*38*38*30 |
1075*3626 |
72 |
38*38*65 |
1030*4040 |
141 |
40*40*40 |
1010*4040 |
81 |
19*19*38*38*38 |
1220*3660 |
92 |
25*25*50*50*50 |
1220*3660 |
62 |
Product Features
Industrial corrosion resistant fiberglass frp grating frp plastic platform grating
Corrosion resistant
Has very excellent acid-proof, alkali resistance, resistance to organic solvents and salt, and many other gas and liquid medium corrosion performance, has the incomparable superiority in the field of anti-corrosion.According to the requirements of the actual use, it is economical to choose the base material for the use of phthalic, polystyrene, and vinyl resin.
Comparing with other floor materials, FRP moulded grating provides a series of benefits, unmatched impact resistance, while the strength-weight-ratio is only one-fourth of that of steel grating. It is easy to cut and install. FRP moulded grating is made of continuous fiberglass fully soaked in unsaturated polyester resin giving a uniform structure and perfect bi-directional mechanical properties.
1) Corrosion and chemical resistant
2) High strength ,light weight and good bearing capacity
3) Fire retardant
The flame propagation rate of ordinary flame-retardant grille (ASTM E-84) does not exceed 25; the flame propagation rate of advanced flame-retardant vinyl grille does not exceed 10. The oxygen index is not less than 28 (GB 8924).
4) Slip-resistant and Anti-aging the life time about more than 20 years.
7) Easy maintenance
product displays
Product production process
Product application
Corrosion resistant FRP/GRP molded resin Plastic fiberglass mesh gratings is a glass fiber reinforced material, unsaturated polyester resin matrix, through a special processing composite with a lot of space, FRP grating can be used as structure Materials, corrosive environment for the floor, trench cover, platform, ship deck, stairs, plank road and so on.
Construction |
Guardrails, stairs, ladders, wall gratings, platforms, etc. |
Drainage treatment |
Drainage ditch, drain grating, platform, structure, etc. |
Civil Engineering |
Floors, sidewalks, bridges, tree protection, car washes, parking lots, Protect grating, etc. |
Chemical Industry |
Work platform etc. |
Food processing and aquaculture |
The platform, engineering guardrail, etc. |
Ocean industry |
Platforms, fencing, sidewalks, etc. |
Process &Packing
Packing Details : Packing, pallet,wooden box,or as the order....
Delivery Details : 15-30 days after deposit for frp grating
Delivery Details : 15-30 days after deposit for frp grating
