Product introduction
High quality fiberglass floor grating plastic walkway grid grating panel
FRP Molded Grating is a structural panel which uses high-strength E-Glass roving as reinforcing material, thermosetting resin as matrix and then casted and formed in a special metal mold. It provides properties of light weight, high strength, corrosion resistance, fire resistance and anti-skid. FRP Molded Grating is widely used in oil industry, power engineering, water & waste water treatment, ocean survey as working floor, stair tread, trench cover, etc. and is an ideal loading frame for corrosion circumstances.
★Composite Fiberglass Grating Surface types:
Common surface types:
* Naturally concave surface.
* Polished smooth surface.
* Sanding surface.
Common surface types:
* Naturally concave surface.
* Polished smooth surface.
* Sanding surface.
FRP gratings naturally have concave surfaces, so as to anti skid and ensure safety.
FRP gratings with sanding surfaces have excellent anti-skid characteristic to ensure safety.
FRP gratings with polished smooth surfaces have beautiful appearances and stable structures.
The diamond shape surface makes the FRP gratings anti-skid and safe.
The gritted top covered surface can not only anti skid but also enhance the strength
The sanding surfaces are non-slid to ensure the safety of people on them.
★Molded FRP Fiberglass Gratings Specifications
Mesh shape |
Thickness(mm) |
Mesh size(mm) |
panel dimension(mm) |
Open Area(%) |
Weight (kg/m2)
|
Square mesh
|
13mm |
38*38 |
1220*3660 |
87 |
5.5 |
13mm |
50*50 |
1220*3660,2000*2000 |
82 |
6.5 |
|
25mm |
38*38 |
1000*3017,1000*4083,1220*3660, |
70 |
12.5 |
|
25mm |
40*40 |
1000 × 2000, 1000 × 3000, 1000 × 4000, 1200 × 3000 |
65 |
13.5 |
|
30mm |
38*38 |
1000 × 3017, 1000 × 4083, 1220 × 3660 |
65 |
14.5 |
|
30mm |
40*40 |
1000 × 2000, 1000 × 3000, 1000 × 4000, 1200 × 3000 |
53 |
15.4 |
|
38mm |
38*38 |
1000 × 3017, 1000 × 4083, 1220 × 3660 |
70 |
18.5 |
|
38mm |
40*40 |
1000 × 2000, 1200 × 3000, 1000 × 4000, 1500 × 3000 |
70 |
19.5 |
|
Mini square mesh
|
30mm |
19*19/38*38 |
1000 × 2000, 1000 × 3000, 1000 × 4000, 1200 × 2000, 1200 × 4000, 1500 × 3000 |
44 |
16.5 |
38mm |
19*19/38*38 |
1000 × 2000, 1000 × 4000, 1200 × 2000, 1200 × 4000 |
45 |
21.5 |
|
50mm |
19*19/38*38 |
1220 × 3660 |
44 |
26.5 |
|
Micro Square mesh
|
30mm |
15*15 |
1000 × 3000 |
45 |
19.5 |
30mm |
13*13 |
1000 × 4083, 1220 × 3660 |
53 |
18.5 |
|
38mm |
13*13 |
1000 × 4083, 1220 × 3660 |
53 |
22.5 |
|
Heavy Duty Square mesh
|
50mm |
50*50 |
1220 × 3660, 1220 × 4010 |
48 |
21.5 |
55mm |
50*25 |
1500 × 3000 |
50 |
30.5 |
|
60mm |
38*38 |
1220 × 3660 |
63 |
45.5 |
|
Rectangular Mesh
|
25mm |
100*25 |
1000 × 2000, 1000 × 3000, 1000 × 4000 |
69 |
13.5 |
28mm |
100*50 |
1500 × 2000, 1500 × 4100 |
58 |
9.5 |
Product details
Product features
fiberglass molded grating walkway frp mini mesh grating Fire prevention
The Fire preventionrate of ordinary flame-retardant grille (ASTM E-84) does not exceed 25; the flame propagation rate of advanced flame-retardant vinyl grille does not exceed 10. The oxygen index is not less than 28 (GB 8924).
fiberglass molded grating walkway frp mini mesh grating Corrosion protection
It has excellent acid resistance, alkali resistance, organic solvent and salt resistance and many other gas and liquid corrosion properties, and it has incomparable superiority in the field of anti-corrosion. According to the requirements of actual use occasions, o-phthalic, isophthalic, and vinyl resins can be economically selected as the matrix material.
It also have slip and age resistant and
good bearing capacity
It has excellent electrical insulation and no breakdown under 10KV voltage; it has no electromagnetic properties and can be used on magnetically sensitive equipment; the special structure of the glass fiber reinforced plastic grille also has the characteristics of anti-skid and anti-fatigue.
Applicable scenarios
fiberglass molded grating walkway frp mini mesh grating Applicable scenarios
industry,pharmaceutical manufacturing, metal smelting,sewage treatment,transportation,water plant breeding,pulp and paper,shipbuilding,civil architecture etc. The concrete uses include operating platform,overhauling walkways, driling platform,terrace,stair steps,equipment aisle,trench over,boat deck,fence etc.
Packing&Shipping
About packaging and transportation
Fiberglass molded gratings undergo a very serious creation process to ensure that the resultant panels are very quality. We put
pride in our packaging and delivery system and we see to it that the client gets the package free from any issue. Make an order
and we will deliver you a quality well packed fiberglass molded gratings.
