SIMCom Cat-NB/GSM LPWA Module R7072

SIMCom Cat-NB/GSM LPWA Module R7072 thumbnail-1
SIMCom Cat-NB/GSM LPWA Module R7072 photo-1
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Association
Year Established:
1999
Annual Export Value:
US$50 Million - US$100 Million
Contact Supplier Request Quote Chat Now
Shenzhen Hurryup Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Description
R7072
● R7072 is the LPWA module which supports wireless communication modes of Cat-NB/GPRS. ● R7072 adopts LCC form factor and has a compact size of 24mm*24mm which makes it ideal for compact products design. ● R7072 has powerful expansibility with abundant interfaces including UART, GPIO, I2C etc. The R7072 is designed for applications that need low latency, low throughput data communication in a variety of radio propagation conditions. Due to the unique combination of performance, security and flexibility, this module is ideally suited for M2M applications, such as metering, asset tracking, remote monitoring, E-health etc.

Product Advantages

● With Power Saving Mode(PSM) and Extended Discontinuous Reception(eDRX), R7072 can extend battery life up to 10 years
● R7072 provides deeper coverage enhancement compared to GSM
General Features
Power Consumption
Frequency Bands:
Cat-NB B3/B5/B8/B20/B28
GSM 900/1800MHz
Supply voltage range: 3.4V ~ 4.2V
Control Via AT Commands
Operation temperature: -30℃ ~ +75℃
Dimensions: 24*24*2.5mm
Weight: 2.7±0.2g
PSM: 4.5uA
Sleep: 0.7mA
Idle:
(AT+CSCLK=0；AT+CFUN=1）
GSM Typ.:11mA
NB-IOT Typ:9.5mA
eDRX: 0.8mA (PTW=25.6s；eDRX=162.84s；DRX=2.56s)
Data
Other Features
Cat-NB:
Uplink 15.625Kbps
Downlink 127Kbps
GPRS:
Uplink 171.2Kbps
Downlink :21.25 Kbps
TCP/UDP/HTTP/HTTPS
PING/MQTT/TLS*/DTLS*
LWM2M/COAP
Firmware update via UART
FOTA
Interfaces
Certifications
UART
SIM (1.8V/3.0V)
I2C
GPIO
ADC
RoHS* / REACH*

CE*
RoHS/REACH
Why Choose Us
FAQ
Q1. What is the minimum order quantity for your products? A1. Minimum order quantity starts from ONE piece. Q2. What's the quality of your products? A2. We have professional QA/QC team to ensure the quality before shipment. We provide 1 year warranty for all the new and original products. Q3. Is this product free of shipping or free samples? A3. Regularly the sample and shipping cost will be at the buyer's account. But in specific case, we may take these costs. Please kindly check with us the details by email. Thank you.
