Description

SIM7600G-H

• The SIM7600G-H is Multi-Band LTE-FDD/LTE-TDD/HSPA+ and GSM/GPRS/EDGE module solution in a SMT type which supports LTE CAT4 up to 150Mbps data transfer.

• It has strong extension capability with rich interfaces including UART,USB2.0, GPIO etc. The module provides much flexibility and ease of integration for customer's application.

• The package of SIM7600G-H is LCC+LGA. The package (LCC part) of SIM7600G-H is compatible with SIM7600x-H (LTE CAT-4 Variants module with LCC package).

• AT commands of SIM7600G-H are mostly compatible with SIM7500/SIM7600 Series modules. This also minimize the investments of customers, and enables a short time-to-market.

• It is designed for applications that need high throughput data communication in a variety of radio propagation conditions. Due to the unique combination of performance, security and flexibility, this module is ideally suited for many applications.

Product advantages
• LCC+LGA package.
• Downlink up to 150Mbps,Uplink up to 50Mbps.
• The AT commands of SIM7600G-H are mostly compatible with SIM7500/SIM7600 Series modules.

General Features
• Supply voltage range: 3.4V ~ 4.2V, Typ: 3.8V
• Control Via AT Commands
• Operation temperature: -40°C to +85°C
• Dimensions: 30.0*30.0*2.9mm
• Weight: 5.7g
• LTE-FDD/LTE-TDD/UMTS/HSDPA/HSUPA/HSPA+/
GSM/GPRS/EDGE

Data
• LTE CAT4
- Uplink up to 50Mbps
- Downlink up to 150Mbps
• HSDPA/HSUPA
- Uplink up to 2.2Mbps
- Downlink up to 2.8Mbps
• HSPA+
- Uplink up to 5.76Mbps
- Downlink up to 42.0Mbps
• UMTS
- Uplink/Downlink up to 384.0Kbps
• EDGE
- Uplink/Downlink up to 236.8Kbps
• GPRS
- Uplink/Downlink up to 85.6Kbps

Other Features
• USB2.0 with High speed up to 480Mbps • UART
• (U)SIM card (1.8V /3.0V)
• Digital Audio through PCM
• SGMII*
• MMC/SD
• SDIO
• ADC
• I2C
• GPIO
• Antenna: Support Primary/Rx-diversity /GNSS

Interfaces
• USB Driver for Microsoft Windows 2000/XP/Vista/Win7/Win8/Win10
• USB Driver for Linux /Android
• RIL supporting for Android 2.3/4.0/5.0/6.0/7.0
• MBIM to Win8
• Firmware update via USB
• TCP/ IP/ IPV4/ IPV6/ Multi-PDP/ FTP/ FTPS/ HTTP/
HTTPS/SMTP/SMTPS/DNS
• SSL3.0/TLS1.0/TLS1.2
• DTMF (Sending and Receiving)
• Audio Playing
• USB Audio and VoLTE
• FOTA

Approval(plan)
• RoHS*
• REACH*
• CE*
• FCC*
* Under Development

Frequency
LTE-FDD:
B1/ B2/ B3/ B4/ B5/ B7/ B8/ B12 /B13 /B18/ B19/ B20/ B25/ B26/ B28/ B66
LTE-TDD:
B34/B38/B39/B40/B41
UMTS/HSDPA/HSPA+:
B1/B2/B4/B5/B6/B8/B19
GSM/GPRS/EDGE:
850/900/1800/1900MHz
