150Mbps/50Mbps EG25-G LTE Cat.4 Module, LCC/Mini PCIe Form Factor EG25 G, EG25G, EG25GGB-256-SGNS
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
- LTE Module EG25-G LTE Category 4 Module 4G EG25
- EC21-A LTE Category 1 Module 10Mbps/5Mbps 4G LTE Module EC21
- EC21AU EC21 AU 4G Module, 10Mbps/5Mbps LTE Cat.1 Module EC21-AU
- EC21-AUX IoT/M2M-Optimized LTE Cat 1 Module 10Mbps/5Mbps, GNSS Optional GSM UMTS LTE Module EC21 AUX
- EM160R-GL LTE Cat.16 4G M.2 Module, 1Gbps/150Mbps LTE-A LTE Module GPS GLONASS BeiDou Galileo EM160 EM160R GL
- EM160R-GL 1Gbps/150Mbps LTE Cat.16 M.2 LTE Module Support GPS GLONASS BeiDou Galileo, 4G Module EM160 EM160R GL
Product Description
Description
EG25-G LGA
● The EG25-G is an LTE category 4 module in an LGA form factor measuring 29.0mm x 32.0mm x 2.4mm, which meets the 3GPP Release 11 standard. It is compatible with Quectel’s UMTS/HSPA+ UC20 and UC200T modules, and multi-mode LTE Standard EC2x (EC25, EC21, EC20, EC20 R2.0 and EC20 R2.1) and EG21-G modules, enabling flexible migration between them.
● The module delivers maximum downlink rates of 150Mbps and uplink rates of 50Mbps under LTE, and backward compatibility with existing 2G networks ensures connection even in remote areas without 3G or 4G coverage. In addition multiple-input multiple-output (MIMO) technology meets demands for data rate and link reliability.
● EG25-G supports Qualcomm® IZat™ location technology Gen8C Lite (GPS, GLONASS, BeiDou/Compass, Galileo and QZSS) and the optional multi-constellation GNSS receiver greatly simplifies product design and provides quicker, more accurate and more dependable positioning.
● A wide range of internet protocols, industry-standard interfaces and functionalities (such as USB serial drivers for Windows 7/8/8.1/10, Linux, Android) allow the module to serve a wide range of IoT applications such as industrial routers, industrial PDAs, rugged tablet PCs, and digital signage.Key Features
● Worldwide LTE, UMTS/HSPA+ and GSM/GPRS/EDGE coverage
● Supports MIMO
● Supports DFOTA and DTMF
● Multi-constellation GNSS receiver available
● USB 2.0 high-speed interface
EG25-G Mini PCIe
● The EG25-G Mini PCIe is an LTE category 4 module in a standard PCI Express® Mini Card form factor measuring 51.0mm x 30.0mm x 4.9mm, which meets the 3GPP Release 11 standard.
● Delivering maximum downlink rates of 150Mbps and uplink rates of 50Mbps under LTE, the EG25-G Mini PCIe supports a range of applications that require fast and reliable transmission of large amounts of data, and backward compatibility with existing EDGE and GSM/GPRS networks ensures connection even in remote areas without 3G or 4G coverage. In addition multiple-input multiple-output (MIMO) technology meets demands for data rate and link reliability.
● The EG25-G Mini PCIe supports Qualcomm® IZat™ location technology Gen8C Lite (GPS, GLONASS, BeiDou/Compass, Galileo and QZSS), and the optional multi-constellation GNSS receiver greatly simplifies product design and provides quicker, more accurate and dependable positioning. A wide range of internet protocols, industry-standard interfaces and functionalities (such as USB serial drivers for Windows 7/8/8.1/10, Linux, Android and eCall) allow the module to serve a wide range of IoT applications such as industrial routers, industrial PDAs, rugged tablet PCs, and digital signage.
Key Features
● Worldwide LTE, UMTS/HSPA+ and GSM/GPRS/EDGE coverage
● Supports MIMO
● Supports DFOTA and DTMF
● Multi-constellation GNSS receiver available
● USB 2.0 high-speed interface
