Sierra AirPrime WP7607-1 IoT Module 4G LTE Cat-4 LPWA Modules With 2G 3G Fallback
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Association
Year Established:
1999
Annual Export Value:
US$50 Million - US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Sierra Wireless AirPrime WISMO228 ModuleNegotiableMOQ: 1 -
Sierra Wireless LTE 4G Modules EM7565 for GlobalNegotiableMOQ: 1
-
Sierra Wireless AirPrime WP7605 IoT Module 3G 4G LTE Cat-4 Module for JapanNegotiableMOQ: 1
-
Sierra Wireless AirPrime WP7608-1 IoT Module 4G LTE 3G 2G ModulesNegotiableMOQ: 1
-
Sierra Wireless AirPrime WP7601 4G LTE IoT ModuleNegotiableMOQ: 1
Description
AirPrime WP7607-1 IoT Module
Reliable Cat-1 LTE connectivity for 4G networks with 3G and 2G fallback in EMEA
The WP7607-1 module is part of the WP Series offering a secure device-to-cloud architecture enabling IoT developers to build a Linux-based product on a single module – reducing overall system complexity and time-to-market.
This LTE Cat-1 wireless module is ideal for low-bandwidth IoT applications that require real-time communication along with the longevity and network quality that 4G LTE networks bring.
Delivering up to 10Mbps download speed, many organizations are using Cat-1 networks as a stepping stone to low-power wide-area (LPWA) networks as 4G LTE can provide a superior user experience over 2G and 3G technologies.
Reliable Cat-1 LTE connectivity for 4G networks with 3G and 2G fallback in EMEA
The WP7607-1 module is part of the WP Series offering a secure device-to-cloud architecture enabling IoT developers to build a Linux-based product on a single module – reducing overall system complexity and time-to-market.
This LTE Cat-1 wireless module is ideal for low-bandwidth IoT applications that require real-time communication along with the longevity and network quality that 4G LTE networks bring.
Delivering up to 10Mbps download speed, many organizations are using Cat-1 networks as a stepping stone to low-power wide-area (LPWA) networks as 4G LTE can provide a superior user experience over 2G and 3G technologies.
4G LTE
Category
Cat-1
Frequency Bands
B1, B3, B7, B8, B20, B28
3G
HSPA+, UMTS
B1, B8
2G
EDGE, GSM, GPRS
900, 1800
DATA SPEED
Peak Download Rate
10Mbps
Peak Upload Rate
5Mbps
LOCATION SERVICES
Satellite Systems
Optional: GPS, Galileo, Glonass, Beidou
CORES
Application Core
ARM® Cortex™- A7 (1.3GHz)
Telecom Core
QDSP6
EMBEDDED SOFTWARE
Firmware
Secure boot, Pre-certified firmware
Embedded Platform
Legato® open source
Linux Distribution
Yocto, Long-term supported Linux Kernel (LTSI)
Audio
Codec: HR, FR, EFR, AMR, Echo Cancellation & Noise Reduction (Optional), Digital Audio, DTMF, I2S, PCM, VoLTE (SKU dependent)
System Drivers
Windows® 7, Windows® 8, Windows® 10, Linux Driver: Standard ECM
INTERFACES
UART
2
USB
1
I2C
1
ADC
4
GPIO
18
Tx ON Indicator
1
SIM interface 1.8V/3V
1
SPI
1
SDIO
1
Flash LED output
1
HARDWARE
CF3 Form Factor
LGA, Snap-in socket option
Dimensions
22x23x2.5mm
Antenna
Diversity, MIMO
Temperature Range
Industrial Grade: -40°C / +85°C
APPROVALS
Carrier
Sierra Wireless
Regulatory
GCF
EMBEDDED SIM
Optional Ready-to-Connect (Sierra Wireless USIM)*
CLOUD SERVICES
Free Unlimited FOTA upgrades, Connectivity Management option, Device Management option
Category
Cat-1
Frequency Bands
B1, B3, B7, B8, B20, B28
3G
HSPA+, UMTS
B1, B8
2G
EDGE, GSM, GPRS
900, 1800
DATA SPEED
Peak Download Rate
10Mbps
Peak Upload Rate
5Mbps
LOCATION SERVICES
Satellite Systems
Optional: GPS, Galileo, Glonass, Beidou
CORES
Application Core
ARM® Cortex™- A7 (1.3GHz)
Telecom Core
QDSP6
EMBEDDED SOFTWARE
Firmware
Secure boot, Pre-certified firmware
Embedded Platform
Legato® open source
Linux Distribution
Yocto, Long-term supported Linux Kernel (LTSI)
Audio
Codec: HR, FR, EFR, AMR, Echo Cancellation & Noise Reduction (Optional), Digital Audio, DTMF, I2S, PCM, VoLTE (SKU dependent)
System Drivers
Windows® 7, Windows® 8, Windows® 10, Linux Driver: Standard ECM
INTERFACES
UART
2
USB
1
I2C
1
ADC
4
GPIO
18
Tx ON Indicator
1
SIM interface 1.8V/3V
1
SPI
1
SDIO
1
Flash LED output
1
HARDWARE
CF3 Form Factor
LGA, Snap-in socket option
Dimensions
22x23x2.5mm
Antenna
Diversity, MIMO
Temperature Range
Industrial Grade: -40°C / +85°C
APPROVALS
Carrier
Sierra Wireless
Regulatory
GCF
EMBEDDED SIM
Optional Ready-to-Connect (Sierra Wireless USIM)*
CLOUD SERVICES
Free Unlimited FOTA upgrades, Connectivity Management option, Device Management option
Why Choose Us
FAQ
Q1. What is the minimum order quantity for your products?
A1. Minimum order quantity starts from ONE piece.
Q2. What's the quality of your products?
A2. We have professional QA/QC team to ensure the quality before shipment. We provide 1 year warranty for all the new and original products.
Q3. Is this product free of shipping or free samples?
A3. Regularly the sample and shipping cost will be at the buyer's account. But in specific case, we may take these costs. Please kindly check with us the details by email. Thank you.
