( Simcom 3g Module ) Sim5218 Sim5215 Sim5320
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Association
Year Established:
1999
Annual Export Value:
US$50 Million - US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
3G/HSDPA SIM 5320 Module With GPS/A-GPSNegotiableMOQ: 1 -
EG91-E LTE Cat-1 Module, EG91 4G Module for IoT and M2M ApplicationNegotiableMOQ: 1
-
EG91-EX 4G LTE Module for EMEA Region LTE Cat-1 EG91NegotiableMOQ: 1
-
EG91-NA 4G LTE Module, EG91 Cellular Module for IoT ApplicationNegotiableMOQ: 1
-
BG96 LTE Cat M1 & Cat NB1 & EGPRS ModuleNegotiableMOQ: 1
Description
( simcom 3g module ) sim5218 sim5215 sim5320
• The SIM5218 series is a Tri-Band/Single-Band HSPA/WCDMA and Quad-Band GSM/GPRS/EDGE module solution which supports up to 7.2Mbps downlink speed and 5.76Mbps uplink speed services.
• It has strong extension capability with rich interfaces including UART, USB2.0 high speed, Embedded SIM Card, SD Card, Camera sensor, GPS, etc. With abundant application capability like embedded LUA script, TCP/ UDP/ FTP/ HTTP/ SMTP/ POP3 and MMS, it will add much value to customers’ application. It is ideal for a wide range of products including USB Modems, gateways, router, PDA, Video phone, and much more.
Control Via AT Commands
• Supply voltage range: 3.3V~ 4.2V
• Dimension: 58*26*4.5mm
• Weight: 15g
• Temperature: -20 °C to +70 °C
• Restricted operation temperature: -30 °C to -20 °C, +70 °C to +80 °C
• Storage temperature: -40 °C to +85 °C
Specification for A-GPS/GPS
• A-GPS: MS-Based, MS-Assisted,
• Stand-alone GPS
Specification for Network Identity and Time zone (NITZ)
• Support in GSM and WCDMA
Specification for video call
• DTMF on H245
• Support standard WCDMA 64kbps(CS) Video call
Specification for SMS
• Point to point MO and MT
• Text and PDU mode
Specification for Voice
• Voice codec: HR,FR, EFR
• AMR
• DTMF
Specification for Data transfer
HSDPA
- Max.7.2Mbps(DL)
- UE Category: 4, 6, 8, 12
HSUPA:
- Max.5.76Mbps(UL)
HSUPA+HSDPA
- Max. 2.0Mbps(UL)+3.6Mbps(DL)
UMTS
- Max.384Kbps(DL), Max.384Kbps(UL)
EDGE Class:
- Max. 236.8Kbps(DL),Max.118Kbps(UL)
GPRS
- Max. 85.6Kbps(DL), Max.42.8Kbps(UL)
CSD
- GSM data rate 14.4Kbps
- WCDMA data rate 57.6Kbps
Advanced features
• SIM5218A: Tri-Band UMTS/HSPA 850/1900/2100MHz
• SIM5218E: Tri-Band UMTS/HSPA 900/1900/2100MHz
• SIM5218C: Single-Band UMTS 2100MHz
• USB 2.0 high speed or UART
• Embedded SIM Card (option)
• A-GPS/GPS positioning
• Video call with camera sensor interface
• WCDMA Equalizer
• WCDMA Diversity
General features
• HSDPA 7.2Mbps
• HSUPA 5.76Mbps
• GPRS multi-slot class 12
• EDGE multi-slot Class 12
• UMTS/HSDPA 3GPP release 5
• UMTS/HSUPA 3GPP release 6
• GSM 3GPP release 99
• SIM5218A: Tri-Band UMTS/HSPA 850/1900/2100MHz
• SIM5218E: Tri-Band UMTS/HSPA 900/1900/2100MHz
• SIM5218C: Single-Band UMTS 2100MHz
• USB 2.0 high speed or UART
• Embedded SIM Card (option)
• A-GPS/GPS positioning
• Video call with camera sensor interface
• WCDMA Equalizer
• WCDMA Diversity
General features
• HSDPA 7.2Mbps
• HSUPA 5.76Mbps
• GPRS multi-slot class 12
• EDGE multi-slot Class 12
• UMTS/HSDPA 3GPP release 5
• UMTS/HSUPA 3GPP release 6
• GSM 3GPP release 99
• Output power
- UMTS 850/900/1900/2100: 0.25W
- GSM850/GSM900: 2W
- DCS1800/PCS1900: 1W
- UMTS 850/900/1900/2100: 0.25W
- GSM850/GSM900: 2W
- DCS1800/PCS1900: 1W
Control Via AT Commands
• Supply voltage range: 3.3V~ 4.2V
• Dimension: 58*26*4.5mm
• Weight: 15g
• Temperature: -20 °C to +70 °C
• Restricted operation temperature: -30 °C to -20 °C, +70 °C to +80 °C
• Storage temperature: -40 °C to +85 °C
Specification for A-GPS/GPS
• A-GPS: MS-Based, MS-Assisted,
• Stand-alone GPS
Specification for Network Identity and Time zone (NITZ)
• Support in GSM and WCDMA
Specification for video call
• DTMF on H245
• Support standard WCDMA 64kbps(CS) Video call
Specification for SMS
• Point to point MO and MT
• Text and PDU mode
Specification for Voice
• Voice codec: HR,FR, EFR
• AMR
• DTMF
Specification for Data transfer
HSDPA
- Max.7.2Mbps(DL)
- UE Category: 4, 6, 8, 12
HSUPA:
- Max.5.76Mbps(UL)
HSUPA+HSDPA
- Max. 2.0Mbps(UL)+3.6Mbps(DL)
UMTS
- Max.384Kbps(DL), Max.384Kbps(UL)
EDGE Class:
- Max. 236.8Kbps(DL),Max.118Kbps(UL)
GPRS
- Max. 85.6Kbps(DL), Max.42.8Kbps(UL)
CSD
- GSM data rate 14.4Kbps
- WCDMA data rate 57.6Kbps
Why Choose Us
FAQ
Q1. What is the minimum order quantity for your products?
A1. Minimum order quantity starts from ONE piece.
Q2. What's the quality of your products?
A2. We have professional QA/QC team to ensure the quality before shipment. We provide 1 year warranty for all the new and original products.
Q3. Is this product free of shipping or free samples?
A3. Regularly the sample and shipping cost will be at the buyer's account. But in specific case, we may take these costs. Please kindly check with us the details by email. Thank you.
