EG91-EX 4G LTE Module for EMEA Region LTE Cat-1 EG91
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Association
Year Established:
1999
Annual Export Value:
US$50 Million - US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
EG91-NA 4G LTE Module, EG91 Cellular Module for IoT ApplicationNegotiableMOQ: 1 -
BG96 LTE Cat M1 & Cat NB1 & EGPRS ModuleNegotiableMOQ: 1
-
EG91-NA 4G LTE Module, EG91 M2M IoT Module for North America RegionNegotiableMOQ: 1
-
Wavecom Wireless CPU Q24PL002NegotiableMOQ: 1
-
Sierra Wavecom GSM/GPRS/GPS Module WISMO228 WISMO 228NegotiableMOQ: 1
Description
Overview
EG91 is a series of LTE category 1 modules optimized specially for M2M and IoT applications. Adopting 3GPP Rel. 11 LTE technology, it delivers maximum data rates up to 10Mbps downlink and 5Mbps uplink. These make EG91 an ideal solution for numerous IoT applications that are not reliant on high speed connectivity but require the longevity and reliability of LTE network.
EG91 contains 6 variants: EG91-E, EG91-EX, EG91-NA, EG91-NS, EG91-VX and EG91-NAX. EG91 is pin-to-pin compatible with UMTS/HSPA+ module UG95/UG96 and LPWA module BG95/BG96. And it is backward-compatible with existing GSM/GPRS and UMTS/HSPA+ networks, ensuring that it can be connected even in remote areas devoid of 4G network coverage.
A rich set of Internet protocols, industry-standard interfaces and abundant functionalities (USB serial drivers for Windows 7/8/10, Linux and Android, etc.) extend the applicability of the module to a wide range of M2M and IoT applications such as smart metering, wearable devices, environmental monitoring, asset tracking, fleet management, safety and alarm systems and so on.
Key Benefits
● Cost-effective and low-power LTE connectivity optimized for broadband IoT applications
● Multi-band LTE, UMTS/HSPA+ and GSM/GPRS/EDGE coverage
● Compact SMT form factor ideal for size-constrained applications with extended operation temperature range
● Embedded power management unit (PMU) featuring ultra-low deep-sleep current consumption
● Simple migration from 2G/3G to 4G with a flexible and scalable platform
Frequency |
EG91-E |
EG91-EX |
EG91-NA |
EG91-NAX |
EG91-NS |
EG91-VX |
||||||
LTE FDD |
B1/B3/B7/B8/B20/B28A |
B1/B3/B7/B8/B20/B28 |
B2/B4/B5/B12/B13 |
B2/ B4/ B5/ B12/ B13/ B25/ B26 |
B2/B4/B5/B12/B13/B25/B26 |
B4/B13 |
||||||
WCDMA |
B1/B8 |
B1/ B8 |
B2/B4/B5 |
B2/ B4/ B5 |
B2/ B4/ B5 |
|||||||
GSM/EDGE |
B3/B8 |
B3/B8 |
||||||||||
Region |
EMEA |
EMEA |
North America |
North America |
North America |
North America |
||||||
Certification |
Carrier: Deutsche Telekom Regulatory: GCF/ CE/ RCM/ FAC/ Anatel Others: WHQL |
Regulatory: GCF/ CE/ RCM Others: WHQL |
Carrier: Verizon/ AT&T/ T-Mobile/ U.S. Cellular/ Rogers/ Telus Regulatory: GCF/ FCC/ PTCRB/ IC Others: WHQL |
Carrier: Verizon*/ AT&T*/ T-Mobile*/ Sprint*/ U.S. Cellular*/ Rogers*/ Telus* Regulatory: GCF/ FCC/ IC/ PTCRB Others: WHQL |
Carrier: Verizon/ AT&T/ Sprint/ Telus T-Mobile* Regulatory: GCF/ FCC/PTCRB/ IC Others: WHQL |
Carrier: Verizon* Regulatory: GCF/ FCC Others: WHQL |
||||||
* Under development |
||||||||||||
