SIM900 SIMCOM GPRS Gps Wifi Gsm MODULE
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Association
Year Established:
1999
Annual Export Value:
US$50 Million - US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
SIMCOM Communication Module SIM800 2G GSM GPRS Module Wireless Transceiver Moduels SIM800 SIM800C SIM800L SIM800A SIM800FNegotiableMOQ: 1 -
Simcom Sim900 Micro Mtk Gsm Module Gsm SimconNegotiableMOQ: 1
-
SIMCOM Distributor Wholesale New & Original GSM/GPRS+GNSS Module SIM868ENegotiableMOQ: 1
-
SIM868 SIMCOM GSM GPS Combo ModuleNegotiableMOQ: 1
-
Smallest Gps Gsm Module Sim900NegotiableMOQ: 1
Description
SIM900 GSM/GPRS Module
• SIMCom presents an ultra compact and reliable wireless module-SIM900. This is a complete Quad-band GSM/GPRS module in a SMT type and designed with a very powerful single-chip processor integrating AMR926EJ-S core, allowing you to benefit from small dimensions and cost-effective solutions.
• Featuring an industry-standard interface, the SIM900 delivers GSM/ GPRS 850/ 900/1800/ 1900MHz performance for voice, SMS, Data, and Fax in a small form factor and with low power consumption.
• Featuring an industry-standard interface, the SIM900 delivers GSM/ GPRS 850/ 900/1800/ 1900MHz performance for voice, SMS, Data, and Fax in a small form factor and with low power consumption.
• With a tiny configuration of 24mm x 24mm x 3 mm, SIM900 can fit almost all the space requirements in your M2M applications, especially for slim and compact demands of design.
General features
* Quad-Band 850/ 900/ 1800/ 1900 MHz
* GPRS multi-slot class 10/8
* GPRS mobile station class B
* Compliant to GSM phase 2/2+
Class 4 (2 W 850/ 900 MHz)
Class 1 (1 W 1800/1900MHz)
* Dimensions: 24*24*3mm
* Weight: 3.4g
* Control via AT commands (GSM 07.07 ,07.05 and SIMCOM enhanced AT Commands)
* SIM application toolkit
* Supply voltage range : 3.2 ... 4.8V
* Low power consumption: 1.0mA(sleep mode)
* Operation temperature: -40°C to +85 °C
Specifications for Fax
* Group 3, class 1
Specifications for Data
* GPRS class 10: max. 85.6 kbps (downlink)
* PBCCH support
* Coding schemes CS 1, 2, 3, 4
* CSD up to 14.4 kbps
* USSD
* Non transparent mode
* PPP-stack
Specifications for SMS via GSM/GPRS
* Point to point MO and MT
* SMS cell broadcast
* Text and PDU mode
Software features
* 0710 MUX protocol
* embedded TCP/UDP protocol
* FTP/HTTP
Special firmware
* FOTA
* MMS
Java (cooperate with Iasolution)
* Embedded AT
Specifications for Voice
* Tricodec
Half rate (HR)
Full rate (FR)
Enhanced Full rate (EFR)
* Hands-free operation
(Echo suppression)
* AMR
Half rate (HR)
Full rate (FR)
Interfaces
* Interface to external SIM 3V/ 1.8V
* analog audio interface
* RTC backup
* SPI interface (option)
* Serial interface
* Antenna pad
* I2C
* GPIO
* PWM
* ADC
Compatibility
* AT cellular command interface
Certificates
* CE
* FCC
* ROHS
* PTCRB
* GCF
* IC
* ICASA
* REACH
Carrier Approvals
* AT&T
* NCC
* Anatel
* Rogers
* Orange
* Vodafone
* Quad-Band 850/ 900/ 1800/ 1900 MHz
* GPRS multi-slot class 10/8
* GPRS mobile station class B
* Compliant to GSM phase 2/2+
Class 4 (2 W 850/ 900 MHz)
Class 1 (1 W 1800/1900MHz)
* Dimensions: 24*24*3mm
* Weight: 3.4g
* Control via AT commands (GSM 07.07 ,07.05 and SIMCOM enhanced AT Commands)
* SIM application toolkit
* Supply voltage range : 3.2 ... 4.8V
* Low power consumption: 1.0mA(sleep mode)
* Operation temperature: -40°C to +85 °C
Specifications for Fax
* Group 3, class 1
Specifications for Data
* GPRS class 10: max. 85.6 kbps (downlink)
* PBCCH support
* Coding schemes CS 1, 2, 3, 4
* CSD up to 14.4 kbps
* USSD
* Non transparent mode
* PPP-stack
Specifications for SMS via GSM/GPRS
* Point to point MO and MT
* SMS cell broadcast
* Text and PDU mode
Software features
* 0710 MUX protocol
* embedded TCP/UDP protocol
* FTP/HTTP
Special firmware
* FOTA
* MMS
Java (cooperate with Iasolution)
* Embedded AT
Specifications for Voice
* Tricodec
Half rate (HR)
Full rate (FR)
Enhanced Full rate (EFR)
* Hands-free operation
(Echo suppression)
* AMR
Half rate (HR)
Full rate (FR)
Interfaces
* Interface to external SIM 3V/ 1.8V
* analog audio interface
* RTC backup
* SPI interface (option)
* Serial interface
* Antenna pad
* I2C
* GPIO
* PWM
* ADC
Compatibility
* AT cellular command interface
Certificates
* CE
* FCC
* ROHS
* PTCRB
* GCF
* IC
* ICASA
* REACH
Carrier Approvals
* AT&T
* NCC
* Anatel
* Rogers
* Orange
* Vodafone
Why Choose Us
FAQ
Q1. What is the minimum order quantity for your products?
A1. Minimum order quantity starts from ONE piece.
Q2. What's the quality of your products?
A2. We have professional QA/QC team to ensure the quality before shipment. We provide 1 year warranty for all the new and original products.
Q3. Is this product free of shipping or free samples?
A3. Regularly the sample and shipping cost will be at the buyer's account. But in specific case, we may take these costs. Please kindly check with us the details by email. Thank you.
