Grundfos DMH 2,81-200D B-SS/V/C-R-E2B6B6XEMAG
USD $2 - $2222
/ Piece
1 Piece(Min.Order)
- 888 Piece / Pieces per Month
- SHENZHEN
- T/T L/C D/P D/A Credit Card PayPal Cash Escrow Other
- 7 days
You May Like
-
Siemens 1FK7105-2AF71-1QA0
-
Siemens SIMOTICS S 1FK7022 Synchronous Servo Motors 1FK7100-2AF71-1RG1
-
Siemens SIMOTICS S 1FK7032 Synchronous Servo Motors 1FK7032-2AK71-1CB0
-
Siemens SIMOTICS S 1FK7042 Synchronous Servo Motors 1FK7044-4CF71-1CH0
-
Siemens SIMOTICS S 1FK706 Synchronous Servo Motors 1FK7060-5AF71-1PB3
-
Siemens 1FK7086-4CC71-1RB1 SIMOTICS S 1FK708 Synchronous Servo Motors
Product Details
| Brand Name: | Grundfos | Place of Origin: | Belgium | Model Number: | DMH 2,81-200D B-SS/V/C-R-E2B6B6XEMAG |
| Application: | Other, KPG.500.15.4.T.50.11.L.38 No. 99552219 | Fuel: | Other, KPG.500.15.4.T.50.11.L.38 No. 99552219 | Power: | Electric |
| Usage: | Air Pump | Theory: | Other, KPG.500.15.4.T.50.11.L.38 No. 99552219 | Standard or Nonstandard: | Standard |
| Structure: | Piston Pump | Pressure: | High Pressure |
Product Description
| Product name | DMH 2,81-200D B-SS/V/C-R-E2B6B6XEMAG |
| Product No | 99823891 |
| EAN number | 5713834809804 |
Technical
| Nominal flow rate at 50 Hz | 2.81 l/h |
| Number of dosing heads | 2 |
| Approvals | CE,EAC,CNROHSEX |
| Non return valve type, inlet pump 1 | Ball valve, spring-loaded |
| Non return valve type, outlet pump 1 | Ball valve, spring-loaded |
| Max viscosity | 5 mPas |
Materials
| Pump housing | Aluminium |
| Dosing head, pump 1 | Stainless steel |
| EN 1.4571 | |
| Dosing head, pump 2 | Stainless steel |
| EN 1.4571 | |
| Valve ball | Ceramic |
| Al2O3 | |
| Valve seat | Composite |
| PTFE | |
| Valve gasket | FKM |
| Rubber |
Installation
| Max operating pressure at 50 Hz | 200 bar |
| Maximum permissible inlet pressure | 1 bar |
| Type of inlet connection | Cutting ring |
| Type of outlet connection | Cutting ring |
| Size of inlet connection | 4/6 |
| Size of outlet connection | 4/6 |
Liquid
| Pumped liquid | Water |
| Liquid temperature range | -10 .. 90 °C |
| Selected liquid temperature | 20 °C |
| Density | 998.2 kg/m³ |
Electrical data
| Power input P1 | 0.2 kW |
| Mains frequency | 50 Hz |
| Max. frequency | 50 Hz |
| Rated voltage | 3 x 230/400 V |
| Enclosure class (IEC 34-5) | IP65 |
| Cable included (Yes/No) | N |
| Power plug | No plug |
Controls
| Type of connector | No plug |
| Type of control variant | Standard |
| Frequency converter | Not prepared for VFD |
Others
| Net weight | 23 kg |
| Gross weight | 34.3 kg |
| Shipping volume | 0.156 m³ |
| Diaphragm Leakage Detection | N |
