| Model 8 bar 116 Psi | Capacity m3/min | Capacity CFM | Motor Power kW Service factor 1,0 |
| OPC 45 – 8 | 7,7 | 272 | 45 |
| OPC 55 – 8 | 9,5 | 335 | 55 |
| OPC 75 – 8 | 12,8 | 452 | 75 |
| Model 10 bar 145 Psi | Capacity m3/min | Capacity CFM | Motor Power kW Service factor 1,0 |
| OPC 45 – 10 | 7,2 | 254 | 45 |
| OPC 55 – 10 | 8,8 | 311 | 55 |
| OPC 75 – 10 | 12,1 | 427 | 75 |
| Model 8 bar 116 Psi | Capacity m3/min | Capacity CFM | Motor Power kW Service factor 1,0 |
| OPC 90 – 8 | 16,5 | 583 | 90 |
| OPC 110 – 8 | 20,0 | 706 | 110 |
| OPC 132 – 8 | 23,0 | 812 | 132 |
| Model 10 bar 145 Psi | Capacity m3/min | Capacity CFM | Motor Power kW Service factor 1,0 |
| OPC 90 – 10 | 15,0 | 530 | 90 |
| OPC 110 – 10 | 18,0 | 636 | 110 |
| OPC 132 – 10 | 21,5 | 759 | 132 |
| Model 8 bar 116 Psi | Capacity m3/min | Capacity CFM | Motor Power kW Service factor 1,0 |
| OPC 160 – 8 | 27,1 | 957 | 160 |
| OPC 200 – 8 | 32,1 | 1134 | 200 |
| Model 10 bar 145 Psi | Capacity m3/min | Capacity CFM | Motor Power kW Service factor 1,0 |
| OPC 160 – 10 | 24,2 | 855 | 160 |
| OPC 200 – 10 | 29,5 | 1042 | 200 |
| Model 8 bar 116 Psi | Capacity m3/min | Capacity CFM | Motor Power kW Service factor 1,0 |
| OPC 250 – 8 | 42,5 | 1501 | 250 |
| OPC 280 – 8 | 47,1 | 1663 | 280 |
| OPC 315 – 8 | 53,0 | 1872 | 315 |
| OPC 355 – 8 | 58 | 1925 | 355 |
| Model 10 bar 145 Psi | Capacity m3/min | Capacity CFM | Motor Power kW Service factor 1,0 |
| OPC 250 – 10 | 38,5 | 1360 | 250 |
| OPC 280 – 10 | 42,7 | 1508 | 280 |
| OPC 315 – 10 | 48,0 | 1695 | 315 |
| OPC 355 – 10 | 54,0 | 1907 | 355 |
