SMC type VM130-01-32 Flat Type 3 Way Manual control Mechanical Valves
Order code
Symbol
Technical parameter
Model |
VM130-01-32 |
Head color |
Red Green Black Yellow |
Fluid |
Air,Inert gas |
Pressure range |
0-1.0 Mpa |
Proof pressure |
1.5Mpa |
temperature |
-5 to 60℃ |
Cv value |
2.5mm2 |
Port size |
G1/8:(Side ported) M5*0.8(Bottom ported) |
Lubrication |
Not required |
Dimension
Feature
1)Working media: 40um filtered air
2)Joint pipe bore: G1/4 3/8 1/2
3) Operating pressure: 0-0.8Mpa
4) Operating temperature: 0-60oC
