AVENTICS Precision Pressure Regulator, Series PR1 – RGP – R412010259
US$ 1 - 2222
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
AVENTICS Precision pressure regulator,
Place of Origin:
Denmark
Model Number:
PR1 – RGP – R412010259
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
7 days
Related Products
-
AF COMPRESSORS 40F50330/468 Cylinder Head 40C94229/478 1st StageUS$ 1 - 22222MOQ: 1 Piece -
AF Oil-free Compressors 20S47170/6141 .20C17112US$ 1 - 22222MOQ: 1 Piece
-
AF Compressors OPC 355 - 10US$ 2 - 2224MOQ: 1 Piece
-
Pumps Grundfos CRI10-14 A-FGJ-A-E-HQQE 3x400D 50 HZUS$ 1 - 33333MOQ: 1 Piece
-
Grundfos DMH 2,81-200D B-SS/V/C-R-E2B6B6XEMAGUS$ 2 - 2222MOQ: 1 Piece
Brand Name
AVENTICS Precision pressure regulator,
Place of Origin
Denmark
Model Number
PR1 – RGP – R412010259
| Activation | Mechanical |
| Parts | Precision pressure regulator |
| Relieving exhaust | with relieving air exhaust |
| Housing | Die cast zinc |
| Sealing material | Acrylonitrile butadiene rubber |
| Nominal flow Qn | 480 l/min |
| Compressed air connection | G 1/4 |
| Version | Regulator without pressure gauge |
| Parts | Precision pressure regulator |
| Mounting orientation | Any |
| Working pressure min./max. | 0,5 … 16 bar |
| Ambient temperature min./max. | -10 … 60 °C |
| Medium temperature min./max. | -10 … 60 °C |
| Medium | Compressed air Neutral gases |
| Regulator type | Diaphragm-type pressure regulator |
| Regulator function | with relieving air exhaust |
| Adjustment range min./max. | 0 … 1 bar |
| Pressure supply | single |
| Activation | Mechanical |
| Weight | 1,02 kg |
| The pressure dew point must be at least 15 °C under ambient and medium temperature and may not exceed 3 °C . Relieving exhaust (≤ 10 mbar over set pressure) Mounting: mounting bracket R412004872 or installation in piping | |
| Recommended pre-filtering | 0,3 µm |
| Material |
|---|
| Housing | Die cast zinc |
| Seals | Acrylonitrile butadiene rubber |
