Home > Industrial Equipment & Components > Pump & Vacuum Equipment > Water Pump > Grundfos CR5-20 A-FGJ-A-E-HQQE 3x400D 50HZ Product ID: 96513389
Grundfos CR5-20 A-FGJ-A-E-HQQE 3x400D 50HZ Product ID: 96513389
US$ 1 - 22222
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Grundfos
Place of Origin:
American Samoa
Model Number:
CR5-20 A-FGJ-A-E-HQQE 3x400D 50HZ Product ID: 96513389
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
7 days
Related Products
-
Grundfos NBG 65-40-200/188 AAF2BESBQQEMW1US$ 1 - 2224MOQ: 1 Bag -
Grundfos CR10-07 A-FJ-A-E-HQQE 3x400D 50 HZUS$ 1 - 22233MOQ: 1 Piece
-
Grundfos CR 5-36 A-FGJ-A-E-HQQE No. 96513394US$ 2 - 2222MOQ: 1 Piece
-
AVENTICS Pneumatics Emerson Cylinders ActuatorsUS$ 2 - 2222MOQ: 1 Piece
-
AVENTICS 3/2 Directional Valve Electrically Operated AS1 BOSCH SOV R412014669US$ 1 - 22222MOQ: 1 Piece
Brand Name
Grundfos
Place of Origin
American Samoa
Model Number
CR5-20 A-FGJ-A-E-HQQE 3x400D 50HZ Product ID: 96513389
Application
Other
Fuel
Other
Power
Electric
Usage
Air Pump
Theory
Centrifugal Pump
Standard or Nonstandard
Standard
Structure
Multistage Pump
Pressure
High Pressure
Electrical data
| Motor standard | IEC |
| Motor type | 100LC |
| IE Efficiency class | IE3 |
| Rated power - P2 | 3 kW |
| Power (P2) required by pump | 3 kW |
| Mains frequency | 50 Hz |
| Rated voltage | 3 x 380-415D V |
| Rated current | 6.3 A |
| Starting current | 840-920 % |
| Cos phi - power factor | 0.87-0.82 |
| Rated speed | 2900-2920 rpm |
| Efficiency | IE3 87,1% |
| Motor efficiency at full load | 87.1 % |
| Motor efficiency at 3/4 load | 88.0 % |
| Motor efficiency at 1/2 load | 87.7 % |
| Number of poles | 2 |
| Enclosure class (IEC 34-5) | 55 Dust/Jetting |
| Insulation class (IEC 85) | F |
| Built-in motor protection | PTC |
| Motor No | 85U15510 |
Controls
| Frequency converter | NONE |
Others
Installation| Minimum efficiency index, MEI ≥ | 0.57 |
| Net weight | 53.5 kg |
| Gross weight | 58.8 kg |
| Shipping volume | 0.133 m³ |
| Danish VVS No. | 385902120 |
| t max amb | 60 °C |
| Maximum operating pressure | 25 bar |
| Max pressure at stated temp | 25 bar / 120 °C |
| 25 bar / -20 °C | |
| Type of connection | DIN / ANSI / JIS |
| Size of inlet connection | DN 25/32 |
| Size of outlet connection | DN 25/32 |
| Pressure rating for connection | PN 25 |
| Flange rating inlet | 250 lb |
| Flange size for motor | FT130 |
| Connect code | FGJ |
