Iml Label Die Cutting Machine

Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)

Key Specifications

Business Type:

Association

Year Established:

2000

Annual Export Value:

US$1.5 Million - US$2.5 Million

Kunshan Dapeng Precision Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

iml label die cutting machine

Functional characteristics:

die cutting machine is developed on the basis of imported cutting machine.

The machine body is cast on the whole, and the mahcine enjoys powerfull pressure, stable operation, firm and durable.

It contains an oil gear box which reduces abrasion to the mahcine during the operation,

thus prolonging the life span of the machine, enhacing the utilization ratio of the machine.

"Press itinerary and pull the material length are automatically adjusted by the screen, make moulding-adjustment more convenient

Scope applicable:

The product is developed aiming at the die cutting and forming of various insulating materials such as PVC, film, Mylar,

copper foil, aluminum foil, foam, etc. in the electronic industry.

automatic die cutting machine produced as customized

IML label die cutting machine

ITEM NO.	Pressure	Max feeding width	Die cutting area	Main engine power	Voltage	cutting speed
	Ton	mm	mm	KW	V	times/minute
DP-30 TA	30	500	900*500	7.5	3 phase AC380V 50HZ	25
work table height	max open distance	max traveling distance	precision	packing size	weight	cutting type
mm	mm	mm	mm	CBM	KG	work with mould to achieve kiss cut and die cut
800	100	100	± 0.05	ACCORDINGLY	5500	work with mould to achieve kiss cut and die cut
function :	Used for die cutting genuine leather,microfiber , PE/ PVC/PP etc plastic film , paper , foam, EVA sponge , non woven etc kiss cutting , gasket die cutting ,IN MOLD LABEL DIE CUTTING
