Automatic Roll Rubber Gasket Die Cutting Machine photo-2
Automatic Roll Rubber Gasket Die Cutting Machine photo-3
Automatic Roll Rubber Gasket Die Cutting Machine photo-4
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Association
Year Established:
2000
Annual Export Value:
US$1.5 Million - US$2.5 Million
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us

Automatic roll rubber gasket die cutting machine



ModelPressure TonMax feeding width(mm)Die cutting areaPower
DP-40T40T650650*600mm7.5
DP-50T50T850850*600mm10
DP-80T80T10001000*800mm15



Features:



1. Four columns Fixing Settings System



2. Air Cold Pressing Settings System



3. Oil temperature cooling device and touch screen



4. High-precision abrasive steel plates can make the semi-die –cut and full- die -cut



5. For purchasing the device including (Hot Air Leveling,EPC&LPC opposite sides,Automatic corrective control,Light sensor or CCD printed material counterpoint cutter).



Application:



 Die cutting Forming of the materials for Photoelectric display screen(Protective film,Bright Enhancement Film,Polarizer,Diffuser,Current-carrying plate etc.),Printed circuit board,Precision screen.







Electronic positioning,automatic adjustment, precision and accurate, and the precision and accuracy can be controlled in 0.01 to 0.03 mm,
push board back and forth precision can be controlled in  0.02 to 0.05 mm

There is shockproof board installed at under-chassis , therefore , the machine body is stable and reliable

Applies to punch electronic materials such as aluminum foil ,PET, protective film , Mylar through cutting or kiss cutting,
all kinds of precision components of stamping forming

PLC  + man-machine automatic programming control ,oil system adopts integrated control, and there is photoelectric protection













Automatic roll rubber gasket die cutting machine

Configuration Data
l       Material Pulling Servo Motor        1  Sets
l Normal Geared motors + encoder for mold plate height adjustment     1 set
   cutting blade motor          1 set
l        Material Pulling Roller (PU material)   2 Sets     Made in China
l        PLC                  1 Set     Made in Japan Mitsubishi
l        Touch Screen          1 Set     Made in Taiwan
l        Photoelectric Safety    2 Set    Made in Taiwan          there total 4 pcs , yellow color front 2 pcs , back side 2 pcs
l        Automatic pressure regulating motor          1 Set  Made in Panasonic
l        Main Motor(7.5KW-4)     1 Set    Made in QL TaiWan
l        Oil Pump                   1 Set    Made in Taiwan Danxin
l        Solenoid Valve ,Cooler       1 group   Made in Taiwan Danxin
l        Hydro-cylinder              1 Set
l        Feeding System             1 Set                 3 inch air-shaft + Aluminum roller ,    max  650mm working     width
l        guillotine System              1Set                         max width : 650mm
l        Feeding platform with roller    1Set
l        Mold And Screw Fixed Device      1 Set                  please see picture below
l        Automatic adjustment Press Fit Route Device  1 Set

Automatic roll rubber gasket die cutting machineAutomatic roll rubber gasket die cutting machineAutomatic roll rubber gasket die cutting machineAutomatic roll rubber gasket die cutting machine
