High Speed Hydraulic Punch Press Machine

Kunshan Dapeng Precision Machinery Co., Ltd.
High Speed Hydraulic Punch Press Machine thumbnail-1
High Speed Hydraulic Punch Press Machine thumbnail-2
High Speed Hydraulic Punch Press Machine thumbnail-3
High Speed Hydraulic Punch Press Machine thumbnail-4
High Speed Hydraulic Punch Press Machine thumbnail-5
High Speed Hydraulic Punch Press Machine photo-1
High Speed Hydraulic Punch Press Machine photo-2
High Speed Hydraulic Punch Press Machine photo-3
High Speed Hydraulic Punch Press Machine photo-4
High Speed Hydraulic Punch Press Machine photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Association
Year Established:
2000
Annual Export Value:
US$1.5 Million - US$2.5 Million
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us

Hydraulic High Speed Punch Press Machine
Model: DP-30Ton

Tonnage: 20T~100T available
High Speed Hydraulic Punch Press Machine


Specifications:

Model DP-20T DP-30T
Force 20T 30T
Stroke 100mm 100mm
Max die height 100mm 100mm
Table size 500*400mm 500*400mm
Descending speed 100mm/sec 100mm/sec
Pressing speed 30mm/sec 30mm/sec
Rebounding speed 100mm/sec 100mm/sec
Operating pressure 21Mpa 21Mpa
Die hole Φ30*60L Φ30*60L
Power supply AC380V three phase AC380V three phase
Power 5HP(3.7KW) 5HP(3.7KW)
Oil capacity 120L 150L
Total weight 850Kg 1100Kg
Dimension (L*W*H, mm) 750*1130*2250 750*1250*2300

Note: Customerized requirements are available for design and producing.

Features:
1. Steel 4 POST frame body with high rigidity and free working space
2. Mechanical positioning cylinder for high precision and accuracy production
3. Water cooling system for lasting working time and durable performance
4. Taiwan or Japan made essential parts and electric control system
5. Perfect safety operating protection system

Application:
Multi functions for punching, pressing, cutting, bending, riveting, molding, assembling, etc.
Applied to various industries like precision electronics, hardware, home appliance, telecommunications, automobiles, LED, etc.



 Want to increase your productivity but make cost lower ??
Contact us for more automatic machinery solutions !!
