ZBL-P8100 foundation pile Integrity dynamics Tester detector A/D data collection
ZBL-P8100 foundation pile Integrity dynamics Tester detector A/D data collection is used to assess the integrality of concrete pile and identify the extent and location of the pile detect by using the reflected wave method.
It can be used for testing perfusion pile and hammer pile and also for testing the exposed top surface of constructions such pillars.
ZBL-P8100 foundation pile Integrity dynamics Tester detector A/D data collection provided with 2 channels of data acquisition and can acquire data from an accelerometer or an instrumented hammer or from two accelerometers.
1.High fidelity system design, to ensure that the original waveform distortion
2.True 24 bi A/D data acquisition, the rest waveform is more real, to avoid the noise and signal distortion caused by large floating point amplification
3.1MHz high speed data acquisition, the minimum sampling time resolution of 1μs,can provide more useful information, more conducive to the discovery of shallow defects;
4.Double channel design, allows use the special detection method
5. A new processing method of wavelet analysis, can be more accurate in complex situations of pile integrity judgement
6. Double injection molding, beautiful appearance, small volume, light weight;
7. Waterproof casing, anti shock design, adapt to the harsh environment
8.Semi transparent, high brightness, TFT color LCD screen, more clearly in the sun
ZBL-P8100 foundation pile Integrity dynamics Tester detector A/D data collection
Model |
ZBL-P8100 foundation pile Integrity dynamics Tester detector A/D data collection |
||
Control Mode |
A8 Embedded Platform |
||
Screen |
5.7inch, High Brightness, TFT color LCD screen |
||
Data Storage |
≥4GB |
||
Operation Mode |
Key + touch screen |
||
Sentinel Magnify(time) |
1,2,5,10,20,50,100 adjustable |
||
A/D resoulution(bit) |
A/D resoulution(bit) |
||
Sampling time intervals(μS) |
1~64000 adjustable |
||
Max length of sampling |
4096 |
||
Trigger |
Signal trigger |
||
Noise voltage of the system(mV) |
≤1 |
||
Dynarnic Range(dB) |
≥184 |
||
Amplifier frequency range(Hz) |
10~10K |
||
Time value error |
4096 |
||
Time resolving power(us) |
≤10% |
||
Gain Error(dB) |
≤1% |
||
Work time(h) |
>8 |
||
Number of channels |
2 |
||
Interference between the channels |
≤1% |
||
Transducer/Probe Sensitivity (Acceleration mode) (mv/g) |
≥100 |
||
Frequency range of Probe (Acceleration probe) (Hz) |
0.5~9000 |
||
Port |
Double USB |
||
Wi-Fi |
Yes |
||
Power supply |
Internal:Built-in Battery External: 220VAC/DC
|
||
Operational Environment |
Temperature(℃): -10~+50 Humidity (RH) :<90%
|
||
Trade terms
1. 18 Month's Warranty.
2. Delivery time:3-7 working days after payments received
3. MOQ:1 set.
4. Service express company:TNT/DHL/FedEX.
5. We accept T/T, Western Union, PayPal & Secure Payment.
