Product Description
TUF-2000P Portable ultrasonic flow meter realizes the non- contact measurement. It is ideal for flow surveys and closed-pipe application where non-invasive measurement of liquids is required. Built-in SD card and printer can timely or regularly print pre-set measuring results.
Temperature and heat can also be measured by connecting clamp on temperature tran
Temperature and heat can also be measured by connecting clamp on temperature tran
Specification
Model | TUF-2000P | TUF-2000H | TDS-100H | TDS-100P |
Accuracy | Better than ±1% | ±1% of reading at rates >0.2mps | Better than ±1.0 % | Better than ±1.0 % |
Repeatability | 0.2 | 0.2 | 0.2 | |
Pipe Size | DN 15-6000mm | DN20mm-6000mm | DN 15-6000mm | DN 15-6000mm |
Power Consumption | Less than 1.5W | Less than 1.5W | Less than 1.5W | 2W |
Power | Built-in rechargeable Ni-MH battery (for 20 hours operation) or AC 220V | 3AAA Ni-H built-in batteries. 90~230VAC | 90~230VAC | 220VAC (standard) the battery can working for more than 20 hours |
Output | RS485 | RS 232 | RS 232 | RS485 |
Protection Class | IP65 | IP65 | IP65 | IP65 |
Display | 2x20 character LCD with backlight, support the language of Chinese, English and Italian | 4*16English letters | LCD with backlight. 2x20 letters. | LCD with backlight. 2x20 letters. 4x4+2 keyboard |
Measurement Period | 0.5S | 0.5S | 0.5S | 0.5S |
Liquids Temperature | -30~160ºC | 0160ºC | -40°C~160°C | -30~160ºC |
Environment Humidity | 85% RH | 85% RH | 85% RH | 85% RH |
Measurement Principle | Transit-time ultrasonic flow meter | Transit-time ultrasonic flow meter | Transit-time measurement principle | Transit-time measurement principle |
Pipe Material | Steel, stainless steel, cast iron, copper, cement pipe, PVC, Aluminum | Steel, stainless steel, cast iron, copper, cement pipe, PVC, Aluminum | Steel, stainless steel, cast iron, copper, cement pipe, PVC, Aluminum | Steel, stainless steel, cast iron, copper, cement pipe, PVC, Aluminum |
Heat Meter | Can added PT100 temperature sensor and used as Ultrasonic heat meter | no | no | no |
