Home > Products > Compression Testing Machine > ASTM C469 Concrete Compression Testing/Modulus of Elasticity Testing
ASTM C469 Concrete Compression Testing/Modulus of Elasticity Testing
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
-
Split tensile test/static elastic modulus test compression test machine
-
Electro-hydraulic concrete compression test machine Hydraulic Compression Digital Cube Testing Machine
-
2000kn Automatic Concrete Compression/Elastic Modulus Testing Machine
-
HYE-2000T Automatic Concrete Compression Testing Machine/ Elastic Modulus Test
-
CTM accessories Digital Panel
-
Digital Compression test machine for concrete
Product Description
HYE-2000T Electro-hydraulic Servo Compression Testing Machine
Product Usage and Features
Introduction
This series of testing machines are suitable for concrete and rock compressive strength tests, equipped with appropriate fixtures and measuring devices to meet the concrete split tensile test, flexural test, and static elastic modulus test.
Product features
1. This machine is specially designed for concrete elastic modulus test. It is equipped with professional elastic modulus analysis software and automatic data collection kit. The test process is simple and efficient;
2. This machine adopts a large oil cylinder wide body design, which has a large test space, while reducing the internal pressure of the hydraulic system, making the test process safer and more reliable;
3. This machine uses a combination of servo motor and Mazu gear pump to load, the test process is quiet, and the test data is accurate;
4. This machine adopts a servo control system, which can realize constant rate control, load holding control, low cycle control, stepless speed regulation, and online adjustment of PID parameters;
5. This machine can be used for compressive tests of concrete test blocks, refractory bricks and other blocks, realizing one machine for multiple purposes;
6. Adopting block slide rail structure design, free switching between concrete compression test and elastic modulus test;
7.The Chinese and English interface can be switched freely, making it more convenient and faster for foreign customers to use.
Applicable standards
ISOã€ASTMã€DINã€JIS etc.
Parameters
Name | compression testing machine |
Model | HYE-2000T |
Max. Test Force (KN) | 2000 KN |
Test accuracy | Level 1/0.5 |
Force Value Display Range | 1%-100%FS |
Force Value Display Error | within ±1% |
Framework Type | 4 columns |
Compressed space | 320 mm |
Piston Stroke | 80 mm |
Piston Displacement Velocity | 0-60 mm/min |
Upper Pressure plate size | φ300mm |
Lower Pressure plate size | 300*300mm |
Effective Distance Between Columns | 350 mm |
Host Size | 545*900*1260 mm |
Control Cabinet Size | 654*450*1300 mm |
Total Weight | 1300kg |
Product Details
Application
Contact US
Cangzhou Lovely Technology Co., Ltd. is specialize in Nondestructive Test Instrument and Material Test Machine over 12 years. With advanced technologies and best customer service, our product has exported to over 100 countries and regions, which win favorable comments from customers worldwide.
Our equipment is used throughout the world for testing soil, concrete, cement, asphalt and aggregatematerials. This testing involves evaluations of materials, which are used in construction projects ranging from roads, bridges and tunnels to dams, earthworks, airports, railways, etc.
We adhere to the high standards of product quality, strict requirements, adopting the world-class production equipment, advanced management and production experience, developing the high-quality testing equipment.
Our Customers and patent certificate
Packing & Delivery
Why Choose us ?
Get our in-time reply via email or telephone or instant messenger;
Get best product with excellent quality and competitive price;
One year guarantee for whole machine 24 hours technical support by email or calling teach you to install and operate,always enjoy our considerable & full-side after-sales service;
Feel very convenient since we can help you sourcing and ship products from different factories via one shipment, which to a large extent save your time and cost;
Easily make the payment via West Union, Paypal, T/T for small value order;
