Wholesale Ultrasonic Thickness Gauges Thickness Measuring Instrument for Sale
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Buying Office
Year Established:
2017
Annual Export Value:
US$10 Million - US$50 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2701 Nuclear-free Asphalt Electrical Density Gauge Price (EDG)NegotiableMOQ: 1 -
Digital Sclerometer Hardness Tester/Concrete Test HammerNegotiableMOQ: 1
-
Sclerometer for Concrete or RocksNegotiableMOQ: 1
-
Efficient Sclerometer Concrete Price/Digital Sclerometer for Top EfficiencyNegotiableMOQ: 1
-
Compare Prices on Sclerometer Hardness TesterNegotiableMOQ: 1
Wholesale Ultrasonic Thickness Gauges Thickness Measuring Instrument for sale
Usage Overview
This series of Ultrasonic Thickness Gauges intelligently use pulse-echo and echo-echo detection technology. The advanced digital
signal processing chip greatly improves the detection accuracy and greatly improves the yield in the production process. The
thickness gauge uses a high-resolution true-color LCD screen, and a highly “human-machine” operating system will provide users an
extraordinary experience.
The thickness gauge is suitable for measuring the thickness of metals (such as steel, cast iron, aluminum, copper, etc.),
plastics, ceramics, glass, fiberglass, and any other good conductor of ultrasonic waves. It can be widely used in petroleum,
chemical, metallurgy, shipbuilding, aviation, aerospace and other fields.
signal processing chip greatly improves the detection accuracy and greatly improves the yield in the production process. The
thickness gauge uses a high-resolution true-color LCD screen, and a highly “human-machine” operating system will provide users an
extraordinary experience.
The thickness gauge is suitable for measuring the thickness of metals (such as steel, cast iron, aluminum, copper, etc.),
plastics, ceramics, glass, fiberglass, and any other good conductor of ultrasonic waves. It can be widely used in petroleum,
chemical, metallurgy, shipbuilding, aviation, aerospace and other fields.
Product Description
· Integral design, compact size
· Easy to carry and make work efficient
· Measurement data can be calibrated manually
Specification
Specification |
U100 |
U150 |
Working principle |
Ultrasound(pulse-echo) |
Ultrasound (pulse-echo, echo-echo) |
Scope of test |
0.75-300mm |
0.75-300mm,penetration coating 2-150mm |
Resolution |
0.1mm(＞100mm)/0.1mm(＜100mm) |
0.1mm(＞100mm)/0.1mm(＜100mm) |
Indication accuracy |
±(0.5%H+0.01)mm |
±(0.5%H+0.01)mm |
Unit |
mm/inch |
mm/inch |
Language |
Chinese-English |
Chinese-English |
Scan mode |
25 times/second |
25 times/second |
Frenquency bandwidth |
0.5-15MHz |
0.5-15MHz |
Speed of sound |
1000~9999m/s |
1000~9999m/s |
Optional probe |
High tempetrature/thin wall coarse grain/ small diameter |
Penetration/ High tempetrature/thin wall coarse grain/ small diameter |
2.4 inch HD color screen |
High contrast 320x240 true color LCD screen |
High contrast 320x240 true color LCD screen |
Sound path correction |
Automatic |
Automatic |
Probe connection status indication |
Have |
Have |
Storage |
TF card machine storge, can be exported to save |
TF card machine storge, can be exported to save |
Communication |
USB interface communicates with host computer |
USB interface communicates with host computer |
Dimensions |
145x75x27mm |
145x75x27mm |
The standard configuration |
1 host/1 probe/2 batteries/1 coupling agent/1 set of document/1 box |
1 host/1 probe/2 batteries/1 coupling agent/1 set of document/1 box |
Unpacking display
Our Advantages
1.High-precision thickness measurement: With zero-point calibration and two-point calibration functions, system errors can be
automatically corrected; the speed of sound can be reversed based on known thicknesses to improve measurement accuracy.
2.Scan mode: real-time display of the maximum and minimum values of the measured material.
3.Communication and storage: USB interface can communicate with upper computer to realize online measurement of thickness
measurement data, TF card storage.
4.Thickness measurement of through-coating: The powerful thickness measurement function of through-coating which could avoid the
tedious preparation work of hard grinding. And it only needs treat a slight coating surface for testing thickness measurement
easily.
5.Accurate measurement value: 0.1 /0.01mm resolution. High-precision measurement circuit guarantees 0.1/0.01mm or 0.01/0.001inch
resolution in the entire measurement range.
6.Display interface: 2.4-inch (320 * 240) true color LCD screen as the display interface, the backlight brightness is adjustable,
and the screen is automatically turned off.
automatically corrected; the speed of sound can be reversed based on known thicknesses to improve measurement accuracy.
2.Scan mode: real-time display of the maximum and minimum values of the measured material.
3.Communication and storage: USB interface can communicate with upper computer to realize online measurement of thickness
measurement data, TF card storage.
4.Thickness measurement of through-coating: The powerful thickness measurement function of through-coating which could avoid the
tedious preparation work of hard grinding. And it only needs treat a slight coating surface for testing thickness measurement
easily.
5.Accurate measurement value: 0.1 /0.01mm resolution. High-precision measurement circuit guarantees 0.1/0.01mm or 0.01/0.001inch
resolution in the entire measurement range.
6.Display interface: 2.4-inch (320 * 240) true color LCD screen as the display interface, the backlight brightness is adjustable,
and the screen is automatically turned off.
Any questions, please contact me without hestitation, welcome your inquiry!Price can be negotiated
our customer
Company Profile
` Cangzhou Lovely Group Co.,Ltd. is a professional manufacturer specializing in Testing Equipment,Universal Testing Machine ,Asphalt Tester,Test Moldsand Soil Road Lab Tester,supply verious type of products ..... We assure high quality to you.
· All our products are made in China .Excellent quality with competitive price
Packing & Delivery
· Tianjin port or Qingdao Port deliver by sea and Also can ship by air via express company
FAQ
Q1: Are you a factory or trading company? A: We are a factory specializing in manufacturing all kinds of scaffolding material.
Besides, we could also purchase products as request.
Q2: Where is the loading port?
A: Tianjin port or Qingdao Port.
Q3:How to choose the Transportation Term? A:Usually,we may according to your needs,we may choose the most rasonable freight,then
to select for you.
Q4: What certificates do you have?
A: We have ISO 9001, CE, SGS.
Q5: Do you have an OEM service?
A: Yes. We can provide OEM services according to your requirements.
Q6: What are the payment terms?
A: T/T payment is preferred and other could be accepted, such as L/C, D/P, Western Union, PayPal etc. It is negotiable.
Besides, we could also purchase products as request.
Q2: Where is the loading port?
A: Tianjin port or Qingdao Port.
Q3:How to choose the Transportation Term? A:Usually,we may according to your needs,we may choose the most rasonable freight,then
to select for you.
Q4: What certificates do you have?
A: We have ISO 9001, CE, SGS.
Q5: Do you have an OEM service?
A: Yes. We can provide OEM services according to your requirements.
Q6: What are the payment terms?
A: T/T payment is preferred and other could be accepted, such as L/C, D/P, Western Union, PayPal etc. It is negotiable.
