Product Description
AT845 Temperature & Humidity Impact Chamber is widely used in aviation, aerospace, electronics, IT, instrumentation, electrical products and other simulated test products in the surrounding air temperature changes rapidly under the conditions of the adaptability of the test and to provide reliability testing, product selection for reliability testing of electronic components.
Specification
Model | AT845 |
Working chamber volume | 450×500×600(mm) |
Sample basket size | 300×450×300(mm) |
Temp. range | -20/-40/-50/-60/-70 ~ +150℃ |
High temp. room | Pre-heat temp range :RT-150℃ |
Heating time:≤25min | |
Low temp. room | Pre-heat temp range :RT ~-70℃ |
Cooling time:≤65min | |
Temp. fluctuation | ≤±0.5℃ |
Conversion time | 5~15 seconds |
Power supply | AC380V 50Hz |
Details & Features
★Consists of the high-temperature room, low-temperature room, moving sample basket and refrigeration systems, heating systems and control systems and other components
★Samples are quickly put into a pre-cooled low-temperature chamber or pre-heated high-temperature chamber, so the temperature change speed is very quickly
★The chamber can be used for impact test chamber can also be used as a separate high-temperature box, low temperature box.
★Compact structure, small size
★Using the world's advanced configuration, the principle of advanced and reliable technology, noise and energy conservation are the best control.
Our Company
History
Since 1982 with more than 20 years’ experience
Warranty
Two Year Warranty for whole product
Training
Video and user manual for training
Onsite service
Installation and training service is available
Testing service
Free sample testing before order is available
Lead time
15 working days lead time for most product
Packing & Delivery
Packaging | ||
Dimensions | 1400*900*1600mm | |
Weight | 200kg | |
Packaging Details | 1. The equipment is covered with film is protect it from water vapour during the trip. 2. The box is filled with foam to protect the equipment from impact. 3. Exported wooden box made from plywood, don't need fumigated. | |
Payment
Payment Term | T/T | EXW | 30% T/T in advance, paid the balance before shipment | ||
FOB | |||||
CFR(C&F) | |||||
CIF | |||||
L/C | L/C amount above 50,000 usd, we can accept L/C at sight | ||||
West Union | Amount lower than 5000usd | ||||
West Union | |||||
Delivery Time | 7~10days after receiving payment for one container | ||||
