HY3874 Lab Two Roll Mill is used to mix, scatter and plasticize materials for color matching, quality control and research. It is suitable for masterbatch, PVC, plastic, pigment dispersion on plastics, etc.
1. Our lab two roll mill adopt imported bear, transfer and gear box etc. make the machine more stable and high quality.
2. The roll size can be customized according to requirement
3. Digital display roll gap , 0~8mm adjustable
4. The speed of two rolls can be fixed with a constant friction ratio, or be adjustable with a constant friction ratio, or be adjustable with variable friction ratio
5. With multiple emergency stop device, more safe
6. Available with safety hood to prevent the operator hands stretch into the two rolls (optional)
|
Model |
HY3874 Lab Two Roll Mill |
|
Capacity |
0.5 ~ 2kg |
|
Roll size |
Ø160×400mm or customized |
|
Cooling mode |
Water |
|
Roll gap |
0 ~ 8mm |
|
Speed of front roll |
40 ~ 80rpm, adjustable |
|
Speed of back roll |
40rpm, fixed |
|
Friction ratio |
1:1 ~ 2:1, adjustable |
|
Power supply |
3phase, AC380V, 50Hz |
|
Dimensions (mm) |
1400×600×1200 |
|
Weight |
800 Kg |
