ISO 18553 Carbon Black Dispersion Tester
- T/T Credit Card
You May Like
-
ISO11357 & ASTM E794 Differential Scanning Calorimeter (DSC)
-
ASTM D1603 Carbon Black Content Tester With LCD Display
-
ISO 179 Digital Charpy Pendulum Impact Tester For Plastic
-
ISO 180 & 20126 Digital Izod Impact Tester for Plastic
-
Digital Izod Impact Testing Machine for PE, PP, PVC, ABS, PS
-
Digital Pendulum Impact Testing Machine for PE, PP, PVC, ABS, PS
Product Description
HY4670 Carbon Black Dispersion Tester is a system to determine the carbon black dispersion of polyolefin pipe, fittings and compound material. It is also suitable for pigment dispersion test.
|
ISO 18553 |
GB/T 18251, 2951.41, 19812.1 |
IEC 60811-4-1, 60811-607 |
Note: this Carbon Black Dispersion Tester can conform to but not limit to all the standards above, for more standards conformance, please contact us.
1. Professional image method to measure, high accuracy
2. With standard scale ruler which provided by metrology institute to ensure the accuracy of the particle size measurement
3. Extensive test parameters including size of carbon black pellet (equivalent diameter, area, perimeter, etc.) and shape information (roundness, rectangularity, length-width ratio, etc.)
4. Equipped with professional process program for different products to ensure reliable test result, automatically finish the process from image capture and test result output
5. With flexible data analysis and reporting system, the test reports are saved as Excel form, convenient to save and print
6. Can provide auto-system, improve the degree of automation
|
Model |
HY4670 Carbon Black Dispersion Tester |
|
Eyepiece |
10X |
|
Objective lens |
5X 10X 40X 60X |
|
Microscope |
Upright metallurgical microscope |
|
Measuring range |
1um~1cm |
|
Scale ruler |
1000μm/1μm |
|
Image capture |
Single acquisition or continuous acquisition |
|
Image process |
Automatic |
|
Measuring mode |
Automatic or manual |
|
Imaging resolution |
2592×1944 (5 mega-pixel) |
|
Power supply |
AC220V 50Hz |
|
Weight |
10kg |
