Textile Automatic Single Yarn Warping Machine Factory Price
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
- ISO 4913 Easy Operate Fiber Fibrograph for for labpratory use
- Labpratpry Use Sample Hydro Extractor Mini Spin-drier 5kg
- AATCC 127 Hydrostatic Head Pressure Tester up to 300kPa
- Automatic Textile Single Yarn Warping Machine With Touch Screen Display And PLC Control
- High Quality ASTM Universal Testing Machine for Textile
- Synthetic Fibre Production Melt Spinning Machine with Factory Price
Product Description
Product Description
AT241C Automatic Single Yarn Warping Machine is used for automatic warping of production sample, weaving sample and small batch fabrics for lab. As the textile develops in the direction of small quantity, diverse kind and prompt delivery, so our company has developed AT241C Small Sample Warping Machine on the increasing requirements on product samples. It is widely used in the sampling in the industries including wool spinning, cotton spinning, colored woven and natural silk etc.
Details & Features
Model | AT241C |
Warping width | 200~700mm |
Warping speed | 0~3000m/min (frequency control) |
Warping length | 1.8~18m |
Applicable yarn density | 5~500tex |
Number of bobbins | 8pcs (automatically-changeable) |
Yarn arrangement | Servo motor control with accuracy of 0.01mm reachable |
Applicable warp beam diameter | ¢60mm |
Applicable warp beam length | 300~700mm |
Air pressure required | 0.4~0.8Mpa |
Air consumption | Max. 200L/h |
Power supply | AC380V 50Hz, three-phase |
Dimensions | 4650×1100×1400mm(L×W×H) |
Weight | Approx.1350kg |
Specification
★ Touch screen display and PLC control and software for arranging the laying of yarn;
★ Special design for sample weaving in lab or research and development institute;
★ Accuracy of warp displacement reaches 0.01mm;
★ SMC rotating cylinder used for color selection, accurate and reliable to change yarn;
★ AC frequency converter to control yarn winding, online detect winding speed;
★ Frequency converter control beaming mechanism, ensure constant winding speed while beaming;
★ Pneumatic pressuring and damping structure to acquire even yarn tension;
★ Bobbin creel adopts air pressure tension-relaxation-preventing structure; avoid tension relaxation while changing yarn;
★ Automatic warp break stop and yarn double winding stop;
★ Foot pedal for unwinding;
★ With inching and stop button for the safety of operator;
Our Company
History
Since 1982 with more than 20 years’ experience
Warranty
Two Year Warranty for whole product
Training
Video and user manual for training
Onsite service
Installation and training service is available
Testing service
Free sample testing before order is available
Lead time
15 working days lead time for most product
Packing & Delivery
Packaging | ||
Packaging Details | 1. The equipment is covered with film is protect it from water vapour during the trip. 2. The box is filled with foam to protect the equipment from impact. 3. Exported wooden box made from plywood, don't need fumigated. |
Payment
Payment Term | T/T | EXW | 30% T/T in advance, paid the balance before shipment | ||
FOB | |||||
CFR(C&F) | |||||
CIF | |||||
L/C | L/C amount above 50,000 usd, we can accept L/C at sight | ||||
West Union | Amount lower than 5000usd | ||||
West Union | |||||
Delivery Time | 7~10days after receiving payment for one container |
