Application
Solution & Melt Dry-jet Wet Spinning Tester
AT236 Solution & melt dry-jet wet spinning tester technological process:
Solution kettle (< 450 C) → Metering pump → melt pipe → spinning die → Spin pack → spinneret→ coagulation bath →drafting roller (1) → far infrared ceramic heating box (< 550 C) (1) → drafting roller (2) → far infrared ceramic heating box (< 550 C) (2) → drafting roller (3) → winder.
Details and Features
★ 316L stainless steel frame, durable and nice.
★ Mini size, save space.
Technical specification
Model | AT236 |
Viscosity of spinning solution | 50-200Pa.s |
Monofilament fineness | 0.1-1mm |
Spinning speed | 5m/min-100m/min |
Spinning Temperature | <450 ℃ |
Far Infrared Ceramic Heating Box Temperature | <550 ℃ |
Power supply | 200V, 50Hz |
Our Company
Packing & Delivery
Pakeging | ||
1. The equipment is covered with film is protect it from water vapour during the trip. 2. The box is filled with foam to protect the equipment from impact. 3. Exported wooden box made from plywood, don't need fumigated. | ||
