Portable Gold Mining Screening Sand And Gold Trommel Screen Equipment
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Hot Selling Product Screen Variety Of Materials As Compost Wood Chips And Soil Waste Mobile Trommel Screen
-
Screening Compost Wood Chips Topsoil Cattle And Sheep Dung Mobile Trommel Screen Belt Conveyor
-
Factory Sales High Quality Mobile Gold Mining Screen Big Capacity Trommel Screen for Sell
-
Hot Selling Mini Mobile Alluvial Gold Screening Placer Gold Washing Gold Trommel Screen
-
Factory Price High Quality Fertilizer Rotary Screen Topsoil Trommel Screen Rotary Screen
-
High Effective Screeining Compost Topsoil And Sheep Cattle Dung Screen Mobile Trommel Screen
Product Description
Portable Gold Mining Screening Sand And Gold Trommel Screen Equipment
Product Description
Characteristics of mobile alluvial gold trommel screen machine：
1. Adopting the principle of rolling conveying, the friction coefficient is small, the wear is light, and the mesh hole is not
easy to block.
2. The roller support adopts the integral through-shaft structure, which runs smoothly, does not vibrate, and has low noise.
3. The internal drum screen accessories adopt split design, the structure is simple, and the replacement and repair are quick and convenient.
4. The drum body adopts an effective full sealing structure, which does not dust or pollute.
5. Safe and reliable operation, adopting deceleration transmission, high transmission efficiency, low power distribution, low energy consumption and obvious energy saving effect.
6. Different screen materials can be used according to customer requirements, mesh size, high screening efficiency, long service life and low maintenance cost.
Gold washing trommel working principle:
1. Input of raw materials Raw materials inputted through the entrance of the hopper will be pushed into the trommel screen by the strong water pressure of the shower equipped in the hopper.
2. Selection and cleaning of raw materials Raw materials of the trommel screen will be cleaned and selected by the rotation of trommel screen and by watering of the shower inside, run into the gold dust separate panel.
3. Collecting of gold dust separated Soil and sands with lighter specific gravity will flow away but gold dusts with greater
specific gravity will be staying in the gathering mat to be collected.
Main technical parameter
Model | Capacity (t/h) | Diameter (mm) | Length (mm) | Discharge (mm) | Input (mm) | Dimension ((mm) |
GMTS0519 | 5-10 | 500 | 1910 | 0-100 | ≤300 | 3000x1000x1800 |
GMTS1020 | 10-30 | 1000 | 2000 | 0-100 | ≤300 | 3390×1400×2140 |
GMTS1225 | 30-50 | 1200 | 2500 | 0-100 | ≤300 | 4146×1600×2680 |
GMTS1545 | 50-120 | 1500 | 4500 | 0-100 | ≤400 | 8160×2300×2500 |
GMTS1548 | 80-150 | 1500 | 4800 | 0-100 | ≤400 | 8460×2300×2500 |
GMTS1848 | 100-200 | 1800 | 4800 | 0-100 | ≤400 | 8460×2300×2700 |
GMTS2060 | 200-350 | 2000 | 6000 | 0-100 | ≤400 | 9680×2300x3420 |
Comany Information
Packing & Delivery
