Non-explosion-proof type Electric Cement Shotcrete machine
This shotcrete machine is widely used in the common construction of building.
It is simple structured, easy maintenance, long service life and has other characteristics. The rotor chamber and the discharge elbow materials are made of flexible rubber abrasion. When working, under the action of the pressure can be rushed to the self-cleaning effect, reducing adhesive material and congestion, greatly reduced the maintenance workload of the machine.
The machines set the advantages of wet and dry spray machine at home and abroad in one, it is easy to operate, sprays evenly, and has the advantage of a low dust, low rebound.
It optimized the working environment, and improved the quality of spray layer.
Specificaiton:
|
Production capacity |
5-6m3 / h |
|
water-cement ratio |
0.4
|
|
Conveying pipe diameter |
51mm |
|
Maximum transmission distance (horizontal) |
100m |
|
Maximum transmission distance (height) |
20m |
|
Consumption of air flow |
7-8 m3/min |
|
Working air pressure |
0.20.4MPa |
|
Motor Power |
5.5kw |
|
Voltage |
380v |
|
Machine Gauge |
600mm (762 or 900mm) |
|
Dimension |
1600 × 796 × 1270 (mm) |
|
Total Weight |
700kg |
|
Model |
Capacity |
Air consumption |
Conveying distance |
Material ratio |
Motor power |
Max Aggregate size |
Conveying pipe inner diameter |
Weight |
|
JXPG-5 |
5 m3/h |
7-8 m3/h |
200m- 40m⊥ |
1:3-5 |
5.5kw |
20m |
51mm |
600kg |
|
JXPG-6 |
6-7 m3/h |
10-15 m3/h |
200m- 40m⊥ |
1:3-5 |
7.5kw |
20mm |
51/64mm |
800kg |
|
JXPC-7 |
7-8 m3/h |
10-15 m3/h |
200m- 40m⊥ |
1:3-5 |
7.5kw |
20mm |
51/64mm |
800kg |
|
JXKP-9 |
7-8 m3/h |
10-12 m3/h |
200m- 40m⊥ |
1:4-5 |
5.5kw |
15mm |
51mm |
1350kg |
