High Frequency Industrial Vibrating Sieve Machine Price Vibrating Screen

Gongyi Hengchang Metallurgical Building Material Equipments Plant
High Frequency Industrial Vibrating Sieve Machine Price Vibrating Screen thumbnail-1
High Frequency Industrial Vibrating Sieve Machine Price Vibrating Screen thumbnail-2
High Frequency Industrial Vibrating Sieve Machine Price Vibrating Screen thumbnail-3
High Frequency Industrial Vibrating Sieve Machine Price Vibrating Screen thumbnail-4
High Frequency Industrial Vibrating Sieve Machine Price Vibrating Screen thumbnail-5
High Frequency Industrial Vibrating Sieve Machine Price Vibrating Screen photo-1
High Frequency Industrial Vibrating Sieve Machine Price Vibrating Screen photo-2
High Frequency Industrial Vibrating Sieve Machine Price Vibrating Screen photo-3
High Frequency Industrial Vibrating Sieve Machine Price Vibrating Screen photo-4
High Frequency Industrial Vibrating Sieve Machine Price Vibrating Screen photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Government ministry/Bureau/Commission
Year Established:
1990
Annual Export Value:
US$10 Million - US$50 Million
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Product Description
High Frequency Industrial Vibrating Sieve Machine Price Vibrating Screen
vibrating sieves are used to separate materials into various sizes for further processing or for end use. The material is separated by passing through a vibrating “screen or meshes” which has a number of different sized according to customer’s requirements. The end products can then be used in the building and construction industries. It feature advanced structure, powerful vibrating forces, low vibration noise, easy maintenance, high durability and etc.
vibrating screen machine / vibrating screen price / vibrating screen sieve
The vibrating screen with circular motion is specially designed for quarry to separate crushed stone material into different sizes, and is also used as a grading machine in coal dressing, ore dressing, construction material, electric and chemical industries.
Advantage:
A). Reliable quality certified by CE and reaches European standard.
B). Two types of vibrating screen,
C). Unique and advanced design.
D). Powerful vibrating forces, low vibrating noise
E) Easy to maintain, high durability, etc..
Working principle
The electromotor drives the belt and pulley to make the movable jaw move back and forth, up and down through the eccentric shaft.
The raw material is squashed or splitt when movable jaw plate moves towards fixed jaw together with movable jaw. When movable jaw and movable jaw plate turn back by eccentric shaft and spring, the raw material, which is squashed or split before discharges from the bottom outlet under jaw plate. The bulk-production comes true while electromotor rotates continuously and the movable jaw crushes and discharges the raw material periodically.
vibrating screen machine / vibrating screen price / vibrating screen sieve
The Customer Site
vibrating screen machine / vibrating screen price / vibrating screen sieve.
Company Information:About HENGCHANG
Hengchang headquarters is located in the industrial park in Gongyi City. It covers a total area of 150,000 square meters, including 100,000 square meters of standarized workshop. There are more than 200 sets of various large and medium-sized metal processing lathe, riveting machine, welding equipment and assembly equipment. We have more than 300 workers, including more than 20 middle and senior technicians. Hengchang is mainly focus on 4 series products: stone crusher machines, sand making equipment,
powder grinding mills, mineral processing equipment and their spare parts. Every year,
Hengchang can turn out 1,000 sets of crushers and 10,000 tons of crusher parts.
Customer Visit & Our Service
(A) Pre-sale services:
Act as a good adviser and assistant of clients, enable them to get rich and generous returns on their investments.
1. Select equipment model; 2. Design and manufacture products according to clients' special requirement;
3. Train technical personnel for clients;
4. Services during the sale;
(B)Provide considerate services to minimize clients' worries:
1. Assist clients to prepare for the first construction scheme;
2.Install and debug the equipment;
3. Train the first-line operators;
4. Examine the equipment;
5. Take initiative to eliminate
the troubles rapidly;
6. Provide perfect service;
7. Provide technical exchanges...
(C).After-sale services:Provide considerate services to minimize clients' worries:
1.Assist clients to prepare for the first construction scheme;
2.Install and debug the equipment;
3. Train the first-line operators;
4. Examine the equipment;
5. Take initiative to eliminate
the troubles rapidly;
6. Provide perfect service;
7. Provide technical exchanges..
Manufacturing Technique
Model
Sieve specification (mm)
Layer
Mesh size (mm)
Max feeding size (mm)
Processing capacity (t/h)
Moto power (kw)
Vibrating Frequency (r/min)
Double amplitude (mm)
2YK1237
1200X3700
2
3-50
200
30-100
5.5
970
5-9
3YK1237
1200X3700
3
3-50
200
30-100
7.5
2YK1548
4800X1500
2
3-100
400
30-275
15
3YK1548
4800X1500
3
3-100
30-275
15
2YK1848
4800X1800
2
3-100
56-330
18.5
3YK1848
4800X1800
3
3-100
56-330
18.5
4YK1848
4800X1800
4
3-80
56-330
22
2YK1860
6000X1800
2
3-100
65-586
18.5
3YK1860
6000X1800
3
3-100
65-586
22
4YK1860
6000X1800
4
3-100
65-586
30
980
2YK2160
6000X2100
2
3-100
81-720
22
980
3YK2160
6000X2100
3
3-100
81-720
30
970
4YK2160
6000X2100
4
3-100
81-720
37
980
2YK2460
6000X2400
2
3-150
100-810
22
970
3YK2460
6000X2400
3
3-150
100-810
30
980
4YK2460
6000X2400
4
3-150
150-850
37
980
2YK2470
7000X2400
2
3-100
180-900
30
980
3YK2470
7000X2400
3
3-100
180-900
37
980
4YK2470
7000X2400
4
3-100
180-900
45
980
2YK2480
8000X2400
2
3-150
190-940
30
980
3YK2480
8000X2400
3
3-150
190-940
37
980
4YK2480
8000X2400
4
3-150
190-940
45
980
2YK3070
7000X2400
2
3-100
220-1000
37
980
3YK3070
7000X2400
3
3-150
220-1000
45
980
4YK3070
7000X2400
4
3-150
220-1000
55
980
Our Workshop
1.We are factory and be able to give you the lowest price than market one;
2.Our products have been exported to over 80 countries and widely used in global mining and construction industry;
3.We have a professional after-sale service team to promptly and thoroughly solve your problems; 4. Provide free process design.
Packing and delivery
Packaging Details:We will make different packaging according to different machine sizes standard international export packing,container, wooden box.

Delivery Time:We will customize according to the actual needs of customers. Senior designers start to design the plan. After receiving the deposit, we will complete the delivery within 15 to 25working days.
vibrating screen machine / vibrating screen price / vibrating screen sieve.
FAQ
Q: For providing you the suitable quotation we need to know the following information:
A:
1. What is the raw material?
2. What is the capacity per hour you required ?
3. What is the maximum input size of the raw material ?
4. What is the final briquettes size and shape you want? Once we get your answers, I can provide you the best quotation immediately.

Remarks: The price will depend on different models.

Q: What about Warranty of the products ?
A:
Gongyi hengchang machinary grants our customers a twelve-month-period warranty from the date of delivery for machines exported from us. During the warranty period, in case any defect of material or workmanship occurred with spare parts in norma operation,we will at our discretion replace or repair the defective parts freely.
