Factory Customized Mining Equipment Gravity Mineral Separation 6s Gold Shaking Table Gold Washing Separation For Sale
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Government ministry/Bureau/Commission
Year Established:
1990
Annual Export Value:
US$10 Million - US$50 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Best Selling Large Capacity Gravity Spiral Chute Separator With Good PriceNegotiableMOQ: 1 -
Circular 4 Decks Vibrating Screen Separator Mining Vibrating Feeder Washing Screens Machine Plant Price for Gravel and SandNegotiableMOQ: 1
-
Trommel Drum Screen Rotary Small Rotary Trommel Screener Mining Gold Trommer Scrubber Heavy Dute Rock Trommer Drum For GravelNegotiableMOQ: 1
-
Hot Sale 50tph Trommel Screener Small Rotary Scale Gold Mining Scrubber Heavy Duty Rock Drum Trommer Screen For GravelNegotiableMOQ: 1
-
Heavy Duty Rock Drum Trommel Screen Gravel Separator Rotary Screen Small Mining Gold Scrubber Washing Machine For SaleNegotiableMOQ: 1
Company Profile
Hengchang is a company integrating industry and trade. Its main business is the sale of jaw crushers, drying equipment, and mineral processing equipment. We have our own factory, professional production team, quality control team, 10 years of export experience and many loyal customers. We have experience in exporting products to Southeast Asia, Australia, Europe, South America and Africa, and have gained a good reputation. At the same time, our excellent product quality and best service have won the trust of customers all over the world. Many of our products have obtained CE certification, and most of our partner factories have ISO9001 and IEC certifications. Some have also obtained certification. We believe that our company is your good choice, because we respond quickly to your enquiry, and we will reply you within 4 hours. Our experienced English-speaking trading staff will listen to your requirements and choose the right products for your market according to your requirements.
Product Description
Factory Customized Mining Equipment Gravity Mineral Separation 6s Gold Shaking Table Gold Washing Separation For Sale
Shaking table is widely used for sorting minerals. Its main function is sorting the rough and concentrate mixture after minerals gravity separating. (Such as rough concentrate sorted by jig and shaking table). Process particle size is ranging from 2 mm to 0.074 mm. The separating effect is especially for minerals with a variety of sulfide minerals. It has the following advantages compared with the gold table: it is easy to observe changes of slurry on shaking table; easy to operate; it has many different specifications for choosing.Advantages of Hengchang Shaking Table Separation
Our new designed mineral shaking table is with better quality than normal 6s shaking table.
1.Table Desk of Shaking Table Separation:
Made of emery,epoxy resin and fiberglass fabric. first-grade&most wear-resisting Emery can make the table wearproof, long life time. More thicken fiberglass fabric can support the table more stable and stronger
2.Feeding chute of Shaking Table Separation:
The chute is made of PP material,wearproof.,the old type is wooden which is more easy to be broken.
3.Collection Chute of Shaking Table Separation:
with PP collection chute can collect the concentrate and middling more conveniently, Old type is iron sheet or without this chute.
4.Electric Motor of Shaking Table Separation:
From China famous motor brand,.Also can make SIEMENS brand,customize motor as per request.
5.Channel Frame of shaking table:
#28 big channel frame,50cm more height than normal, so can collect the minerals more conveniently
6.Bearing of shaker table:
From China famous professional bearing manufacturer, Guaranteed quality, long life time.
7.Steel Plate of Gold shaking table:
Steel material,5 mm thick, more thicker than normal (usually 2-4 mm thick)
Our new designed mineral shaking table is with better quality than normal 6s shaking table.
1.Table Desk of Shaking Table Separation:
Made of emery,epoxy resin and fiberglass fabric. first-grade&most wear-resisting Emery can make the table wearproof, long life time. More thicken fiberglass fabric can support the table more stable and stronger
2.Feeding chute of Shaking Table Separation:
The chute is made of PP material,wearproof.,the old type is wooden which is more easy to be broken.
3.Collection Chute of Shaking Table Separation:
with PP collection chute can collect the concentrate and middling more conveniently, Old type is iron sheet or without this chute.
4.Electric Motor of Shaking Table Separation:
From China famous motor brand,.Also can make SIEMENS brand,customize motor as per request.
5.Channel Frame of shaking table:
#28 big channel frame,50cm more height than normal, so can collect the minerals more conveniently
6.Bearing of shaker table:
From China famous professional bearing manufacturer, Guaranteed quality, long life time.
7.Steel Plate of Gold shaking table:
Steel material,5 mm thick, more thicker than normal (usually 2-4 mm thick)
Products Specifications
Model Performance | LS4500 | LY3000 | LY2100 | LY1100 | ||
Screen Size(mm) | 4500× 1850× 1560 | 3000× 1620× 1100 | 2100× 1050× 850 | 1100× 500× 430 | ||
Horizontal Slope | Degree | 0-5 | 0-10 | 0-8 | 0-10 | |
Feeding Range(mm) | Sand ore | -2 | -2 | -2 | -2 | |
slime | -0.074 | -0.1 | -0.074 | -0.074 | ||
Feeding Density | % | 10-30 | 10-30 | 10-30 | 10-30 | |
Capacity (t/h) | Sand ore | 0.5-1.8 | 0.7-1.5 | 0.4-0.8 | 0.1-0.2 | |
slime | 0.5-0.8 | 0.4-1 | 0.3-0.5 | 0.05-0.1 | ||
Water consumption | t/h | 0.4-0.7 | 0.3-1.5 | 0.2-1 | 0.1-0.5 | |
Motor power | kw | 1.1 | 1.1 | 1.1 | 0.55 | |
Dimension (mm) L× W × H | 5600× 1850× 860 | 4075× 1320× 780 | 3040× 1050× 1020 | 1530× 500× 800 | ||
Deck Weight(kg) | 370 | 310 | 180 | 50 | ||
Working Principle
Shaking Table Working principle
This machine belongs to deep tank type flotation cell, equipped with blower for air supply. The flotation cell has U-shaped tank,reducing the slurry sediment to the least, reasonable support structure of the tank, large space between the support, even airdispersion, stable foam in good suspension. The design of impeller structure and the flow channel between impeller blades is reasonable, so that the impellers can be even wore and stator has long service life.
Product &Details
Product Application
Not find same as you want ? Please Click here !
Exhibition & Customer Visit
Customer Site
Our machine has been sold to Germany, Australia, Japan, Mexico, Philippines, Indonesia, Russia, Uganda, Uzbekistan, Zimbabwe, etc. and our products are well received by customers. Welcome to inquiry!
Our Services
Before-sale services:
We guide customers to choose the best and applicable device; provide the advanced, energy-saving and practical technological processes, as well as we are responsible for the planning and design of the site.
Sale services:
Products must be inspected strictly before being sold; customers are invited to simulate and test machine on-the-spot and raise objections; in accordance with the agreements stipulated in the contract, we will arrange delivery.
Products must be inspected strictly before being sold; customers are invited to simulate and test machine on-the-spot and raise objections; in accordance with the agreements stipulated in the contract, we will arrange delivery.
After-sale services:
Our Company will send professional engineers to guide device installation, debug and train operators until customers are fully satisfied. Moreover, we will design and produce machines according to the special requirements of customers.
Our Company will send professional engineers to guide device installation, debug and train operators until customers are fully satisfied. Moreover, we will design and produce machines according to the special requirements of customers.
Solemn Promise:
The quality guarantee period of machines is one year except the wearing parts
Tips:
The prices in the web only to be reference,according to raw material's price fluctuations; Specific price is subject to the negotiation.
Packing and delivery
Packaging Details:Normally the machines are taken apart before delivery and are packed by suitable packing ways, the packing ways are as below: Nude packing. Bundle packing. Grass rope packing. Water proof packing. Wooden pallets packing. Wooden box or carton box packing.
Delivery Time:We will customize according to the actual needs of customers. Senior designers start to design the plan. After receiving the deposit, we will complete the delivery within 15 to 25working days.
FAQ
Q:Why we believe in Gongyi Hengchang company?
A: 1.More than 28 years’ experience.
2.Hengchang is the leading professional supplier of solution, equipment’s and service for
crushing and grinding industry.
3.Products achieved ISO9001:2000 quality management certificate and EU CE certificate.
Q: Deliverytime .
A: The lead time is 10-20 days, Delivery time will vary depending on the type of the machine, shipping method selected and part availability.
Q: Payment terms ?
A: Accepted Payment Type: T/T, L/C, Western Union, Cash and so on. After sign the contract, pay the 10%-30% deposit of total purchase price and pay the full payment before delivery.
Q: what will you do if the machine is broken down?
A: The Products warranty is one year. We will provide the technical advice and find the solution immediately for you when the machine is in trouble. For those wear parts, we guarantee the high quality parts for long-term supply.
Q: What should i do if I want to get a best quotation?
A: If you want a suitable type for you, please let us know your material and capacity.
