Manufacture Factory Price High Viscosity Double Planetary Mixing Machine Chemical Machinery Equipment
- 1000 per Month
- T/T Credit Card
- Manufacture Factory Price High Efficiency Planetary Disperser (5L-1000L) Chemical Machinery Equipment
- Manufacture Factory Price Planetary Mixer for High Viscosity Materials Chemical Machinery Equipment
- Manufacture Factory Price Double Planetary Disperser Chemical Machinery Equipment
- Manufacture Factory Price 500L Planetary Dual Shaft Dissolver Chemical Machinery Equipment
- Manufacture Factory Price Dual Shaft Planetary Disperser 500L Chemical Machinery Equipment
- Manufacture Factory Price 500L Planetary Dispersing Mixer Chemical Machinery Equipment
Product Description
Brief Introduction - Planetary Mixer:
(1) Planetary Disperser is a powerful dispersing and mixing machine.
(2) It combined the theories of traditional double planetary mixer and high speed dispersing mixer, to be an all-round new machine, it has been widely used in many fields at present .
(3) This series planetary disperser is special for high viscosity raw materials, for example, sealant, silicone rubber and industrial adhesives.
Product Features:
1). Integrate mixing, dispersion and wall scraper in one machine.
2). Mechanical seal, O ringseal or trapezoid seal for option material reaction can happen under vacuum condition.
3). High and low speed impellers rotate rapidly and exert strong impact force to mix materials thoroughly in a very short time, no deposit and residuals.
4). With jacket or coil-pipe for heating/cooling, medium can be water, electricity, steam or oil.
5). Configured with PLC automatic control system with human-computer interface for option.
Type | 5L | 15L | 30L | 50L | 100L | 300L | 500L | 1000L | ||
Product Name | Double Planeatary Mixer | Double Planeatary Mixer | ||||||||
Bucket Size (mm) | Ø280× 180 | Ø280× 325 | Ø400× 325 | Ø480× 365 | Ø550× 550 | Ø850× 650 | Ø960× 810 | Ø1160× 1100 | ||
Revolution Motor (Kw) | 1.5 | 2.2 | 3 | 4 | 5.5 | 18.5 | 22 | 30-37 | ||
Revolution Speed (frequency control) r/min | 0-60 | 0-60 | 0-84 | 0-62 | 0-70 | 0-45 | 0-35 | 0-35 | ||
Rotation Speed (frequency control) r / min | 0-100 | 0-100 | 0-130 | 0-75 | 0-110 | 0-62 | 0-60 | 0-45 | ||
Dispersing Motor (Kw) | 1.1 | 2.2 | 2.2 | 5.5 | 5.5 | 11 | 30 | 37 | ||
Vacuum( Mpa) | ≤0.098 | ≤0.098 | ≤0.098 | ≤0.098 | ≤0.098 | ≤0.098 | ≤0.098 | ≤0.098 | ||
Lifting Stroke(mm) | 360 | 400 | 430 | 650 | 700 | 900 | 1000 | 1100 | ||
Weight (kg) | 500 | 800 | 1000 | 2000 | 2300 | 2700 | 3500 | 5000 | ||
Dimensions (mm) | L | 1500 | 1700 | 1700 | 1700 | 1700 | 2500 | 2700 | 2700 | |
W | 900 | 900 | 900 | 900 | 1100 | 1200 | 1500 | 1800 | ||
H | 1700 | 2100 | 2300 | 2300 | 2300 | 2700 | 2900 | 3100 |
Our Company
(1). Our company can design the equipment according to user's specific requirements.
(2). For the fast update of the technology, we will change the technical data without notice, and the right parameters are subject to the real product.
(3).If you are not certain of which type to choose, please call us and our profession sales engineers will recommend for you.
(4).We could give you the rapid response on your inquiry .
We could package the product according to the customer's demand.
Packaging Detail: | wooden carton(can be customized according to user's requests and specifications) |
Delivery Detail: | With 30 days on receiving deposite payment |
