Manufacture Factory Price Laboratory Double Planetary Disperser Chemical Machinery Equipment

FOB Price

Negotiable

1 (Min. Order)

Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

1.Descriptions:

(1)Planetary Disperser ls a powerful dispersing and mixing machine, its regular model is Dual High-speed Dispersing mixer together with anchor type mixer with scraper, has super strong shearing effect and s high mixing efficiency.

(2)This machine is specially suitable for mid-and-high viscosity material and thixotropic material;

(3)There is a set of high speed dispersing agitator can be replaced by the mid-speed agitator, and spiral type, paddle type, frame type mixing pattern are optional. Best agitator type are chosen based on material property and production technology.

2. Features:

1).Integrate mixing, dispersion and wall scraper in one machine.

2). Mechanical seal, or trapezoid seal for option material reaction can happen under vacuum condition.

3). High and low speed impellers rotate rapidly and exert strong impact force to mix materials thoroughly in a very short time.

4). With jacket or coil-pipe for heating/cooling, medium can be water, electricity, steam or oil.

5). Configured with PLC automatic control system with human-computer interface for option.

3.Notes:

(1) The device can be designed according to the user's specific requirements.

(2) Due to the rapid upgrading of technology, the right technical parameters are subject to the real product.

(3) If you have some problems,please call us,then our professional sales engineers will help you.

4.Main technical parameters:

Type		5L	15L	30L	50L	100L	300L	500L	1000L
Product Name		Double Planetary Power Mixer					Double Planetary Dual Drive Mixer
Bucket Size (mm)		Ø280× 180	Ø280× 325	Ø400× 325	Ø480× 365	Ø550× 550	Ø850× 650	Ø960× 810	Ø1160× 1100
Revolution Motor (Kw)		1.5	2.2	3	4	5.5	18.5	22	30-37
Revolution Speed (frequency control) r/min		0-60	0-60	0-84	0-62	0-70	0-45	0-35	0-35
Rotation Speed (frequency control) r / min		0-100	0-100	0-130	0-75	0-110	0-62	0-60	0-45
Dispersing Motor(Kw)		1.1	2.2	2.2	5.5	5.5	11	30	37
Vacuum( Mpa)		≤0.098	≤0.098	≤0.098	≤0.098	≤0.098	≤0.098	≤0.098	≤0.098
Lifting Stroke (mm)		360	400	430	650	700	900	1000	1100
Weight (kg)		500	800	1000	2000	2300	2700	3500	5000
Dimensions (mm)	L	1500	1700	1700	1700	1700	2500	2700	2700
	W	900	900	900	900	1100	1200	1500	1800
	H	1700	2100	2300	2300	2300	2700	2900	3100

Our Product

FAQ

About Trade Term

Q-----What’s the trade term for making business with us?

A----- FOB; It’s mainly depend on client’s requirement;

About Delivery Time

Q------What’s the Delivery time after placing order ?

A------Usually it takes about 25~30 days after we received your deposit.

However, it would depend on our production line schedule(the timing clients place order)and the manufacturing process of the item.

About Payment Term

Q------What’s the Payment Term?

A------ By T/T.(40% by T/T for an order, the balance to be paid before delivery
