Longxing Factory Price 360KW Thermal Oil Heater for Paper Making Chemical Machinery Equipment
- 1000 per Month
- T/T Credit Card
- Manufacture Factory Price Thermal Oil Heater for Reactor Heating Chemical Machinery Equipment
- Manufacture Factory Price Hot Sale Thermal Oil Heater for Petroleum Chemical Machinery Equipment
- Heat Transfer Oil Furnace (Horizontal Oil-Fired)
- Manufacture Factory Price Thermal Oil Heater for Chemical Reactors Chemical Machinery Equipment
- 36KW Thermal Oil furnace
- Manufacture Factory Price horizontal thermal oil heater(coal fired) Chemical Machinery Equipment
Product Description
1. Features:
(1) It runs at a lower pressure and gets a higher operating temperature.
(2) It can get stable heating and precise temperature.
(3) Thermal Oil Heater has complete operational control and security monitoring devices.
(4) Thermal oil furnace helps to save electricity, oil, and water and can recover investment in 3 to 6 months.
2. Brief Introduction:
The Thermal Oil Heater, with stable performance and reliable quality, is examined and approved by the State Technical Supervision Bureau and is tested by Yantai City.
It is efficient heating equipment, which uses electricity as a heat source and heat transfer oil as a heat carrier, passing thermal energy to the heat users through the forced circulation of the hot oil pump, and returning to the Heater for reheating and recirculation.
3. Technical Parameters:
Type Specification |
WDR 0.036 |
WDR 0.06 |
WDR 0.12 |
WDR 0.18 |
WDR 0.24 |
WDR 0.30 |
WDR 0.36 |
||
Heating Power (kW) |
36 |
60 |
120 |
180 |
240 |
300 |
360 |
||
Heat Output (×10³Kj/h) |
129 |
216 |
432 |
648 |
864 |
1080 |
1296 |
||
Highest Operation Temperature |
300 |
||||||||
Temperature Control Accuracy |
±5 |
||||||||
Thermal Efficiency (%) |
>90 |
||||||||
Design Pressure (Mpa) |
0.7 |
||||||||
Oil Cycle (m³ / h) |
10 |
18 |
18 |
18 |
30 |
30 |
45 |
||
Motor Power (kW) |
2.2 |
5.5 |
5.5 |
5.5 |
7.5 |
7.5 |
11 |
||
Connecting Pipe (DN) (mm) |
Output |
32 |
50 |
50 |
50 |
65 |
65 |
80 |
|
Circuit |
32 |
50 |
50 |
50 |
65 |
65 |
80 |
||
Dimensions(mm) |
1785× 560× 1420 |
2000× 550× 1440 |
2000× 800 ×1440 |
200× 800× 1760 |
2000× 900× 1910 |
2000× 940× 2145 |
2000× 940× 2328 |
||
Weight(Kg) |
375 |
495 |
662 |
840 |
1018 |
1350 |
1705 |
1. Shandong Longxing Chemical Machinery Group Co., Ltd is not only the professional base for the chemical machinery but also one of the fixed companies for China National Chemical Equipment Corporation.
2. Our group has the Design License of Special Equipment in Grade D1 &D2, and the Manufacture License of Special Equipment in Grade A1 &A2.
3. We also have the Manufacture License of Special Equipment in Heat Transfer Oil Furance, ISO Quality System Certification, and CE Certification.
(1). Our company can design the equipment according to the user's specific requirements.
(2). For the last update of the technology, we will change the technical data without notice, and the right parameters are subject to the real product.
(3). If you are not certain of which type to choose, please call us and our professional sales engineers will recommend it for you.
(4). We could give you a rapid response to your inquiry.
