PL28-2 Fiber Agitator Laboratory Standard Pulp Disintegrator

fiber agitator laboratory standard pulp disintegrator

PL28-2

PL28-2 type vertical Standard Pulp Disintegrator, its another name is standard fiber dissociation or Standard fiber blender, Pulp fiber raw material at high speed in the water,Bundle fiber dissociation of single fiber. It is used to make sheeth and measure filter degree, The preparation for pulp screening.

Meet the standard of: JIS-P8220, TAPPI-T205, ISO-5263.

Structural features:

This machine is of vertical construction. The container uses the transparent material toughness. The equipment is equipped with RPM control instrument.

Machine is made of stainless steel with a water protective coating

Main parameter:

Pulp:24g oven dry stock, 1.2% concentration,2000ml pulp.

Volume:3.46L

Pulp volume:2000ml

Propeller: φ90mm, R gauge blade conform to the standards

Rotate speed:3000r/min±5r/min

Standard of revolution:50000r

Size:W270×D520×H720mm

Wight:50Kg
