Laboratory Small Benchtop Vacuum Top-press Freeze Dryer

Laboratory Small Benchtop Vacuum Top-press Freeze Dryer thumbnail-1
Laboratory Small Benchtop Vacuum Top-press Freeze Dryer thumbnail-2
Laboratory Small Benchtop Vacuum Top-press Freeze Dryer thumbnail-3
Laboratory Small Benchtop Vacuum Top-press Freeze Dryer thumbnail-4
Laboratory Small Benchtop Vacuum Top-press Freeze Dryer thumbnail-5
Laboratory Small Benchtop Vacuum Top-press Freeze Dryer photo-1
Laboratory Small Benchtop Vacuum Top-press Freeze Dryer photo-2
Laboratory Small Benchtop Vacuum Top-press Freeze Dryer photo-3
Laboratory Small Benchtop Vacuum Top-press Freeze Dryer photo-4
Laboratory Small Benchtop Vacuum Top-press Freeze Dryer photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Distributor/Wholesaler
Year Established:
2015
Annual Export Value:
Below US$1 Million
Contact Supplier Request Quote Chat Now
Nanbei Instrument Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products
Application:
The laboratory freeze-drying machine is a freeze-drying equipment specially developed by NANBEI for laboratory users. It has a desktop or vertical design, compact structure and small footprint; it is suitable for laboratory placement and installation. It is widely used in biopharmaceutical, medical, food and other industries. For example, in the production of biological products, BCG vaccine, meningococcal vaccine, measles vaccine, influenza vaccine, etc.; Western medicine production of Chinese antibiotics, circulatory organ drugs, etc. In the medical field, freeze-drying technology can be used for long-term preservation of various organs such as blood, arteries, bones, skin, cornea, and nerve tissue. NBFD-10 series laboratory freeze dryer products are divided into basic type, gland type, multi-manifold type, multi-manifold gland type.
Features
1. Imported brand compressors, fast cooling speed and large cooling capacity 2. 7-inch color LCD touch screen design, digital and curve display at the same time sample temperature, cold trap temperature and vacuum degree and other freeze-drying parameters 3. Standard USB interface, with historical data query and storage function 4. The inflation valve can be filled with dry inert gas (optional) 5. Cold trap electric defrost function (optional) 6. Separate electric heating function, can explore the pilot freeze-drying process (optional)
Specification
Model
NBFD-10S
(standard)
NBFD-10P
(Multi-manifold common type)
NBFD-10T
(Gland type)
NBFD-10PT
(Multi-manifold gland type)
Cold trap temperature（℃）
≤-60
Vacuum（Pa）
<10
Freeze-dried area （m2）
0.12
0.09
Water catching capacity（Kg/24h）
3
Material loading（ml）
1200
900
Material tray specifications
（ф*h mm）
200*20
Layers of material tray (layers)
4
3
Material/tray (ml)
(Material thickness 10mm)
300
Freeze drying time (h)
24
Number of external freeze-dried bottles (pieces)
/
8
/
8
Vials
(ф22mm)
260
195
(ф16mm)
480
360
(ф12mm)
920
690
Size
（W*D*H）mm


582*541*374/684
Details Images
Recommend Products
Company Profile
Certifications
FAQ
Q1: Why Choose NANBEI ? (1).Professional manufacturer with more than 13 years experience (2).Exported to more than 97% Countries (3).Turnkey Solution is no problem Q2:OEM,ODM acceptable or not? Absolutely Yes Q3:What's kind of Payment terms for customer choosing? T/T ,Western Union, Money Gram , Credit Card, Paypal , L/C ... Q4:Can we visit your factory online? Absolutely no problem Q5:Can online video inspection before shipment? Absolutely no problem Q6: what's the MOQ ? Sample order is OK? MOQ:1 set, sample order is no problem Q7:What's kind of shipment for customer choosing? Usually ship by sea, by air, by international express . We can also provide reasonable solutions according to your transportation requirements Q8:How to ensure product quality and after-sales service? We have CE, ISO quality certificate, and SGS authentication. After-sale service: 1.Warranty : 1 year 2.We supply free part for quality problem in warranty 3.Long life technical support and service
